9-36V Input,5V/20A Output Eighth Brick

High efficiency, 91% (5 V/20A)
Excellent thermal performance
Remote sense, remote control, over-voltage, over-current, short-circuit, and over temperature protection
1500V isolation voltage

SKU: 18EA18050020 Category: Isolated DC-DC Power Converters

Description

18EA18050020 have high efficiency and power density, with no minimum load requirement, maintain excellent performance even with large output capacitors. Built-in input under-voltage lockout, output over-voltage protection, output over-current/short-circuit protection, and over temperature protection are included. A fixed switching frequency of 180-350kHz provides predictable EMI. Filters or EMI application circuitry are available to meet high-reliability EMI requirements. The rugged design is suitable for harsh environments and meets high-reliability standards.

18EA18050020

9-36V Input,5V/20A Output Eighth Brick



Property

Value

Continuous Input (Vdc)

-0.5 to 40

Transient Input Voltage (<100ms continuous operating)

50

Nominal Input Voltage(V)

Sep-36

Output Voltage(V)

5

Enabling Logic options

Positive

Rated Output Current(A)

20

Lout(A)

15-20/20-30

Isolation(Vdc)

1500

Package Size

Quarter-Brick

Features

Wide input voltage range

High Efficiency

Optimal thermal performance

Remote sense, On/Off control

Over-voltage, over-current,short-circuit, and over temperature protection

Monotonic start-up into pre-biased load

1500V isolation voltage

Applications

For High Reliability Applications
