16 GHz to 17 GHz, 0.6 dB Insertion Loss, 18 dB Isolation, GWB Micro-strip Series Isolator-WG1502A8
Micro-strip Series isolator with 16-17 GHz frequency range, 0.6 dB insertion loss, 18 dB isolation
- Description
- Datasheet
- Reviews (0)
Description
The WG1502A8 is a high-performance micro-strip series designed for RF and microwave applications. It operates in the frequency range of 16-17 GHz with 0.6 dB maximum insertion loss and 18 dB minimum isolation.
WG1502A8 | |
| 16 GHz to 17 GHz, 0.6 dB Insertion Loss, 18 dB Isolation, GWB Micro-strip Series Isolator-WG1502A8 | |
Property | Value |
| Frequency (GHz) | 16-17 |
| Bandwidth | 5% |
| Return Loss (dB) |
|
| Isolation (dB) | 18 |
| Insertion Loss (dB) | 0.6 |
| VSWR | 1.3 |
| IMD3 (dBc) |
|
| Power (W) | 10 |
| Reverse Power (W) |
|
| Peak Power |
|
| Power note |
|
| Connector | GWB |
| Impedance(Ohm) | 50 |
| Size |
|
| Operating Temp (degC) | -40 to 85 |
| Structure | surface-mount |
Features | |
| Frequency Range: 16-17 GHz | |
| Insertion Loss: 0.6 dB Max | |
| Isolation: 18 dB Min | |
| VSWR: 1.3 Max | |
| Power: 10 W | |
Applications | |
| Wireless communication, Radar systems, Test and measurement equipment | |
