2.92mm 40 GHz, 0.009″ Accept Pin Diameter, 4 Hole .375″ Square Mounting Flange Male Connector
This Model D361-P09-F02 is a Male connector. 2.92mm (K) Connectors are durable, operational temperature rating of -55°C to +135°C., offering well-matched impedance, excellent repeatability, lowest VSWR, RF leakage ≤ -100 dB.
2.92mm (K) Connectors offers the frequency range from DC to 40 GHz. This model is 4 Hole .375″ Square mounting. This model of 2.92mm (K) Connectors provides the accept pin diameter of 0.009″inches.
- Description
- Reviews (0)
Description
| 2.92mm (K) Connectors | |
| 2.92mm 40 GHz, 0.009″ Accept Pin Diameter, 4 Hole .375″ Square Mounting Flange Male Connector | |
| D361-P09-F02 | |
| This Model D361-P09-F02 is a Male connector. 2.92mm (K) Connectors are durable, operational temperature rating of -55°C to +135°C., offering well-matched impedance, excellent repeatability, lowest VSWR, RF leakage ≤ -100 dB. 2.92mm (K) Connectors offers the frequency range from DC to 40 GHz. This model is 4 Hole .375″ Square mounting. This model of 2.92mm (K) Connectors provides the accept pin diameter of 0.009″inches. | |
| Property | Value |
| Min. Frequency (GHz) | DC |
| Max. Frequency (GHz) | 40 |
| Flange (inch) | .375″ Square |
| Mounting | 4 Hole |
| Accept Pin Diameter (inch) | 0.009″ |
| Gender | Male |
| Features | |
| Low VSWR | |
| Free through 40 GHz | |
| Applications | |
| Telecom Communication | |
| Sub-assemblies | |
| Radio equipment and instruments | |
| Wireless Communication | |
| Test Labs | |
| Instrumentations | |
