1.2 GHz to 3.8 GHz, 0.4 dB Insertion Loss, 23 dB Isolation, TAB Drop-in Series Isolator-TG102M3-10
Drop-in Series isolator with 1.2-3.8 GHz frequency range, 0.4 dB insertion loss, 23 dB isolation
- Description
- Datasheet
- Reviews (0)
Description
The TG0102M3-10 is a high-performance drop-in series designed for RF and microwave applications. It operates in the frequency range of 1.2-3.8 GHz with 0.4 dB maximum insertion loss and 23 dB minimum isolation.
TG0102M3-10 |
|
|
1.2 GHz to 3.8 GHz, 0.4 dB Insertion Loss, 23 dB Isolation, TAB Drop-in Series Isolator-TG102M3-10 |
|
Property |
Value |
|
Frequency (GHz) |
1.2-3.8 |
|
Bandwidth |
5% |
|
Return Loss (dB) |
|
|
Isolation (dB) |
23 |
|
Insertion Loss (dB) |
0.4 |
|
VSWR |
1.2 |
|
IMD3 (dBc) |
|
|
Power (W) |
Connector Type |
|
Reverse Power (W) |
|
|
Peak Power |
|
|
Power note |
|
|
Connector |
|
|
Impedance(Ohm) |
50 |
|
Size |
|
|
Operating Temp (degC) |
-40 to 85 |
|
Structure |
connectorized |
Features |
|
|
Frequency Range: 1.2-3.8 GHz |
|
|
Insertion Loss: 0.4 dB Max |
|
|
Isolation: 23 dB Min |
|
|
VSWR: 1.2 Max |
|
|
Power: Connector Type W |
|
Applications |
|
|
Wireless communication, Radar systems, Test and measurement equipment |
|
