11 GHz, N Female to TNC Male, Between Adapters

11 GHz, N Female to TNC Male, Between Adapters

This model OA345301Z01 is N Female Straight to TNC Male Straight. This series N Female Straight to TNC Male Straight have the operating frequency of 11 GHz. Adapters that have a male to female or plug to jack configuration are known as connector savers.

Between Series Adapters are the passive components which are used to transfer signals from one coaxial connector interface to another with minimal losses. Between adapters have different connector configurations on either side of the adapter.

Description

PDF

Additional information

Min. Frequency (GHz)

DC

Max. Frequency (GHz)

11

VSWR (Max.)

1.15:1

Conector 1

N

Gender 1

Female

Connector 1 Body Style

Straight

Conector 2

TNC

Gender 2

Male

Connector 2 Body Style

Straight

Durability (Cycle)

500

Impedance (Ω)

50
