14.0 GHz to 18.0 GHz, 18.0 dB Insertion Loss, 0.5 dB Isolation, Micro-Strip Series Circulators Isolator-OH5A073-14.0-18.0
$0.00
Miniaturization, light weight
High product consistency
High reliability
Customizable
Suitable for aviation, aerospace, radar, electronic countermeasure, microwave communication, microwave test fields
- Description
- Reviews (0)
Description
The product named OH5A073 is high-performance microstrip circulator that plays a role in impedance matching and decoupling in integrated circuits. It provides functions such as unidirectional transmission and signal processing, featuring a simple production process suitable for microwave hybrid integrated circuits.
OH5A073-14.0-18.0 |
|
|
14.0 GHz to 18.0 GHz, 18.0 dB Insertion Loss, 0.5 dB Isolation, Micro-Strip Series Circulators Isolator-OH5A073-14.0-18.0 |
|
Property |
Value |
|
Frequency (MHz) |
14.0-18 |
|
Return Loss (dB) |
0 |
|
Isolation (dB) |
0.5 |
|
Insertion Loss (dB) |
18 |
|
IMD3 (dBc) |
1.3 |
|
Power (W) |
15 |
|
Operating Temp ( degC) |
15.0 to 5.0 |
Features |
|
|
Miniaturization, light weight |
|
|
High product consistency |
|
|
High reliability |
|
|
Customizable |
|
|
Suitable for aviation, aerospace, radar, electronic countermeasure, microwave communication, microwave test fields |
|
Applications |
|
|
This circulator for microstrip patch antenna is customizable and suitable for aviation, aerospace, radar, electronic countermeasures, microwave communications, and microwave testing fields. |
|
Reviews
There are no reviews yet.
