15.0 GHz to 18.0 GHz, 1.3 dB Insertion Loss, 18.0 dB Isolation, Micro-Strip Series Circulators Isolator-OH5A026-15.0-18.0
$0.00
Small size
Lightweight
High product consistency
High reliability
Customizable
Aviation and aerospace applications
Radar and electronic warfare
Microwave communication
Microwave test fields
- Description
- Reviews (0)
Description
The product named OH5A026 is high-performance microstrip circulator used for impedance matching and decoupling in integrated circuits, providing unidirectional transmission and signal processing functions. They have a simple production process suitable for microstrip hybrid integrated circuits.
OH5A026-15.0-18.0 |
|
|
15.0 GHz to 18.0 GHz, 1.3 dB Insertion Loss, 18.0 dB Isolation, Micro-Strip Series Circulators Isolator-OH5A026-15.0-18.0 |
|
Property |
Value |
|
Frequency (MHz) |
15.0-18 |
|
Return Loss (dB) |
0 |
|
Isolation (dB) |
18 |
|
Insertion Loss (dB) |
1.3 |
|
IMD3 (dBc) |
15 |
|
Power (W) |
15 |
|
Operating Temp ( degC) |
5.0 to 5.0 |
Features |
|
|
Small size |
|
|
Lightweight |
|
|
High product consistency |
|
|
High reliability |
|
|
Customizable |
|
|
Aviation and aerospace applications |
|
|
Radar and electronic warfare |
|
|
Microwave communication |
|
|
Microwave test fields |
|
Applications |
|
|
This circulator for microstrip patch antenna is customizable and suitable for aviation, aerospace, radar, electronic countermeasures, microwave communications, and microwave testing fields. |
|
