15 GHz to 17 GHz, 1.0 dB Insertion Loss, -3.0 dB Isolation, Micro-Strip Series Circulators Isolator-OH5A116-15.0-17.0
$0.00
Miniaturization
Lightweight
High product consistency
High reliability
Customizable
Suitable for aviation, aerospace, radar, electronic countermeasure, microwave communication, microwave test fields
- Description
- Reviews (0)
Description
The product named OH5A116 is high-performance microstrip circulator isolator component mainly used in the receiver and transmitter modules of phased array radar; the three ports are connected tOthe receiver, transmitter and common antenna respectively, making the microwave radiOsignals proceed in an orderly manner, and the receiver and transmitter are isolated from each other, improving the stability of the system; suitable for microstrip hybrid integrated circuit applications.
OH5A116-15.0-17.0 |
|
|
15 GHz to 17 GHz, 1.0 dB Insertion Loss, -3.0 dB Isolation, Micro-Strip Series Circulators Isolator-OH5A116-15.0-17.0 |
|
Property |
Value |
|
Frequency (MHz) |
15000-17000 |
|
Return Loss (dB) |
1 |
|
Isolation (dB) |
-3 |
|
Insertion Loss (dB) |
1 |
|
IMD3 (dBc) |
-2 |
|
Power (W) |
2 |
|
Operating Temp ( degC) |
-3 to 3 |
Features |
|
|
Miniaturization |
|
|
Lightweight |
|
|
High product consistency |
|
|
High reliability |
|
|
Customizable |
|
|
Suitable for aviation, aerospace, radar, electronic countermeasure, microwave communication, microwave test fields |
|
Applications |
|
|
This circulator for microstrip patch antenna is customizable and suitable for aviation, aerospace, radar, electronic countermeasures, microwave communications, and microwave testing fields. |
|
