180-400V Input,12V/90A Output Full Brick
$554.00
High efficiency, 91% (270Vin +/- 7V/90A)
Wide DC input rage 180V-400V
Optimal thermal performance
No minimum load required
Open frame or encapsulated
Fixed frequency operation
Built-in Oring FET
Parallelable
External synchronization
2250Vdc isolation
- Description
- Datasheet
- Reviews (0)
Description
1FA270070090 have high efficiency and power density, with no minimum load requirement, maintain excellent performance even with large output capacitors. Built-in input under-voltage lockout, output over-voltage protection, output over-currentshort-circuit protection, and over temperature protection are included. A fixed switching frequency of 180-350kHz provides predictable EMI. Filters or EMI application circuitry are available to meet high-reliability EMI requirements. The rugged design is suitable for harsh environments and meets high-reliability standards.
1FA270070090 | |
| 180-400V Input,12V/90A Output Full Brick | |
Property | Value |
| Continuous Input (Vdc) | -0.3 to 400 |
| Transient Input Voltage (<100ms continuous operating) | 420 |
| Nominal Input Voltage(V) | 180-400 |
| Output Voltage(V) | 7 |
| Enabling Logic options | Positive |
| Rated Output Current(A) | 90 |
| Lout(A) | 50-90 |
| I/O Isolation Voltage (for 1 minute)(Vdc) | 2250 |
| Package Size | Full Brick |
Features | |
| Wide input voltage range | |
| High Efficiency | |
| Optimal thermal performance | |
| Remote sense, OnOff control | |
| Over-voltage, over-current,short-circuit, and over temperature protection | |
| Monotonic start-up into pre-biased load | |
| 1500V isolation voltage | |
Applications | |
| For High Reliability Applications | |
