2 to 20 GHz 2WAY OPD-0220-2-S With SMA Female Connectors

Description

Outline

PDF

Band Pass Filter Datasheet (Click to download)

Additional information

Min. Frequency (GHz)

2

Max. Frequency (GHz)

20

Insertion Loss (dB), Max.

2

Isolation (dB) Min

15

Amplitude Balance (dB) Max

±0.75

Phase Balance (°) Max

±10

Input Power (W) Max

10
