-15%

40 GHz, 2.92mm Female to 2.92mm Female, IN Adapters

Original price was: $60.Current price is: $51.

This model OA363600Y01 is 2.92mm Female Straight to 2.92mm Female Straight. This series 2.92mm Female Straight to 2.92mm Female Straight have the operating frequency of 40 GHz. Adapters that have a male to female or plug to jack configuration are known as connector savers.

Between Series Adapters are the passive components which are used to transfer signals from one coaxial connector interface to another with minimal losses. Between adapters have different connector configurations on either side of the adapter.

SKU: OA363600Y01 Categories: Adapters and Connectors, IN Series Adapters, RF Adapters

Description

Additional information

Min. Frequency (GHz)

DC

Max. Frequency (GHz)

40

VSWR (Max.)

1.20:1

Conector 1

2.92mm

Gender 1

Female

Connector 1 Body Style

Straight

Conector 2

2.92mm

Gender 2

Female

Connector 2 Body Style

Straight

Durability (Cycle)

500

Impedance (Ω)

50
