7 GHz to 20 GHz, 0.4 dB Insertion Loss, 20 dB Isolation, SMA/N Coaxial Series Isolator-TG801F8
Coaxial Series isolator with 7-20 GHz frequency range, 0.4 dB insertion loss, 20 dB isolation
- Description
- Reviews (0)
Description
The TG501K is a high-performance coaxial series designed for RF and microwave applications. It operates in the frequency range of 7-20 GHz with 0.4 dB maximum insertion loss and 20 dB minimum isolation.
TG501K | |
| 7 GHz to 20 GHz, 0.4 dB Insertion Loss, 20 dB Isolation, SMA/N Coaxial Series Isolator-TG801F8 | |
Property | Value |
| Frequency (GHz) | 7-20 |
| Bandwidth | 10% |
| Return Loss (dB) |
|
| Isolation (dB) | 20 |
| Insertion Loss (dB) | 0.4 |
| VSWR | 1.25 |
| IMD3 (dBc) |
|
| Power (W) | 5 |
| Reverse Power (W) |
|
| Peak Power |
|
| Power note |
|
| Connector | SMA/N |
| Impedance(Ohm) | 50 |
| Size |
|
| Operating Temp (degC) | -40 to 85 |
| Structure | connectorized |
Features | |
| Frequency Range: 7-20 GHz | |
| Insertion Loss: 0.4 dB Max | |
| Isolation: 20 dB Min | |
| VSWR: 1.25 Max | |
| Power: 5 W | |
Applications | |
| Wireless communication, Radar systems, Test and measurement equipment | |
