Absorptive Coaxial SPST Switch from 0.02GHz to 1GHz .OSA0100020100A

Rf echo Absorptive Coaxial Mechanical Switch is an active microwave device, and its frequency range from 0.02GHz to 1GHz . our Absorptive Coaxial Mechanical Switch has Magnetic latching, Operating life of 1 million cycles, etc.

Rf echo Absorptive Coaxial Mechanical Switch is commonly used in Wireless Infrastructure, RF Microwave & VSAT, 5G communicationFiber Optics, Test and measurement Instrument and other applications.

SKU: OSA0100020100A Categories: Routing, SPST, Switch

Description



Additional information

Min. Frequency (GHz)

0.02

Max. Frequency (GHz)

1

VSWR (Max.)

1.5

Switch Type

SPST

RF Input Power (W)

1

Insertion Loss (dB)

1
