Band pass Filter From 30.5~36GHz OBP-332500-5500 With SMA-Female Connectors

Band pass Filter From 30.5~36GHz OBP-332500-5500 With SMA-Female Connectors

Ocean Microwave band-pass filter (Ocean band-pass filter,,abbreviation:abbreviation:OBP) is a filter that allows waves of specific frequency bandto pass through while rejecting other frequency bands.
The product name of this Ocean band-pass filter (OBP) is OBP-332500-5500,itsCenter Frequency(F0) is33.25GHz, it’s Pass Band Bandwidth is 30.5~36GHz,it’s Pass Band Insertion Loss is ≤2.5dB and its Pass Band VSWR is ≤2.0:1. It’s Stop Band frequency is ≥45dB @ 28.75GHz ≥45dB @ 37.75GHz ≥70dB @ 27.75GHz≥70dB @ 38.75GHz.



Availability: Available on backorder SKU: OBP-332500-5500 Categories: Cavity Band Pass Filter, RF Cavity Filter, RF Filters

Description

Ocean Microwave band-pass filter (Ocean band-pass filter,,abbreviation:abbreviation:OBP) is a filter that allows waves of specific frequency bandto pass through while rejecting other frequency bands.
The product name of this Ocean band-pass filter (OBP) is OBP-332500-5500,itsCenter Frequency(F0) is 33.25GHz, it’s Pass Band Bandwidth is 30.5~36GHz,it’s Pass Band Insertion Loss is ≤2.5dB and its Pass Band VSWR is ≤2.0:1. It’s Stop Band frequency is ≥45dB @ 28.75GHz ≥45dB @ 37.75GHz ≥70dB @ 27.75GHz≥70dB @ 38.75GHz.

Outline

Band pass Filter From 30.5~36GHz OBP-332500-5500 With SMA-Female Connectors

Bandpass Filter Datasheet (Click to download)

OBP-325000-5000

Additional information

Center Frequency (F0) (MHz)

33250

Min. Pass Band Frequency (MHz)

30500

Max. Pass Band Frequency (MHz)

36000

Pass Band Insertion Loss (dB)

≤2.5

Stop Band Rejection

≥45dB @ 28.75GHz≥45dB @ 37.75GHz≥70dB @ 27.75GHz≥70dB @ 38.75GHz

Impedance (Ω)

50

Power Handling (W)

≤10

Connection Type

2.92mm-Female
