TNC 18 GHz, 0.036″ Accept Pin Diameter, 4 Hole .687″ Square Mounting Flange Male Connector

TNC 18 GHz, 0.036″ Accept Pin Diameter, 4 Hole .687″ Square Mounting Flange Male Connector

This Mode D401-P36-F07 is a Male connector. TNC connectors are durable, operational temperature rating of -55°C to +165°C, lowest VSWR and RF leakage (≤ -100 dB). TNC Connectors offer the frequency range from DC to 18 GHz.

In TNC Connectors the mounting method is 4 Hole, where the flange sizes is.687″ Square. This model of TNC Connectors provide the accept pin diameter of 0.036″inches.

Description

SPEC

TNC Connector

TNC 18 GHz, 0.036″ Accept Pin Diameter, 4 Hole .687″ Square Mounting Flange Male Connector

D401-P36-F07

This Mode D401-P36-F07 is a Male connector. TNC connectors are durable, operational temperature rating of -55°C to +165°C, lowest VSWR and RF leakage (≤ -100 dB). TNC Connectors offer the frequency range from DC to 18 GHz.

In TNC Connectors the mounting method is 4 Hole, where the flange sizes is.687″ Square. This model of TNC Connectors provide the accept pin diameter of 0.036″inches.

Property

Value

Min. Frequency (GHz)

DC

Max. Frequency (GHz)

18

Flange (inch)

.687″ Square

Mounting

4 Hole

Accept Pin Diameter (inch)

0.036″

Gender

Male

Features

Low VSWR

Free through 18 GHz

Applications

Telecom Communication

Sub-assemblies

Radio equipment and instruments

Wireless Communication

Test Labs

Instrumentations

PDF

Outline

D401 P36 F07 outline TNC 18 GHz, 0.036″ Accept Pin Diameter, 4 Hole .687″ Square Mounting Flange Male Connector

Additional information

Min. Frequency (GHz)

DC

Max. Frequency (GHz)

18

Flange (inch)

Mounting

Accept Pin Diameter (inch)

Gender
