100W Wide Band Power Limiter 0.05 – 6 GHz . OLT8000050600A

RFECHO Power Limiter is an active product, and its frequency range from 0.05GHz to 6GHz . The RFECHO Power Limiter has a High Isolation Limiter, Low insertion loss and good return loss, etc. according to the conditions of different working frequencies, microwave power, microwave pulse width, duty cycle and required interface form, the design of RFECHO limiter has different innovative adjustments.

SKU: OLT8000050600A Categories: Active Device, power limiter

Description















Additional information

Min. Frequency (GHz)

0.05

Max. Frequency (GHz)

6

CW Input Power (W)

80

Peak Power Flat Linkage (dBm)

18

Insertion Loss (dB)

1.8

VSWR

2
