2.496 GHz to 2.69 GHz, 0.25 dB Insertion Loss, 22.0 dB Isolation, Drop-in Series Isolator-OHYH535A-2496-2690
$0.00
Embedded stripline design
High isolation performance
Low insertion loss
High power handling capability
Wide operating temperature range
- Description
- Reviews (0)
Description
The product named OHYH535A-2496-2690 is high-performance stripline embedded circulator designed for telecommunications and microwave applications, offering stable isolation and low insertion loss across its operating range.
OHYH535A-2496-2690 |
|
|
2.496 GHz to 2.69 GHz, 0.25 dB Insertion Loss, 22.0 dB Isolation, Drop-in Series Isolator-OHYH535A-2496-2690 |
|
Property |
Value |
|
Frequency (MHz) |
2496-2690 |
|
Return Loss (dB) |
22 |
|
Isolation (dB) |
22 |
|
Insertion Loss (dB) |
0.25 |
|
IMD3 (dBc) |
-65 |
|
Power (W) |
2 |
|
Operating Temp ( degC) |
30 to 160 |
Features |
|
|
Embedded stripline design |
|
|
High isolation performance |
|
|
Low insertion loss |
|
|
High power handling capability |
|
|
Wide operating temperature range |
|
Applications |
|
|
Designed for telecommunications applications, featuring robust performance and reliable signal isolation. |
|
