27 GHz, 2.4mm Male to SMA Female, Between Adapters

-20%

27 GHz, 2.4mm Male to SMA Female, Between Adapters

$69 $55

Offer Ends In:
33Days09Hours34Minutes00Seconds

This model OA375510Z01 is 2.4mm Male Straight to SMA Female Straight. This series 2.4mm Male Straight to SMA Female Straight have the operating frequency of 27 GHz. Adapters that have a male to female or plug to jack configuration are known as connector savers.

Between Series Adapters are the passive components which are used to transfer signals from one coaxial connector interface to another with minimal losses. Between adapters have different connector configurations on either side of the adapter.

Description

PDF

Additional information

Min. Frequency (GHz)

DC

Max. Frequency (GHz)

27

VSWR (Max.)

1.15:1

Conector 1

2.4mm

Gender 1

Male

Connector 1 Body Style

Straight

Conector 2

SMA

Gender 2

Female

Connector 2 Body Style

Straight

Durability (Cycle)

500

Impedance (Ω)

50
