Biconical antenna is a vertically polarized omnidirectional antenna. Its frequency range is 3 GHz to 18 GHz. its pattern stability is better. Biconical antenna model OBC-30180-10W-1 is used for transmission and immunity test to meet various EMC standards. Its broadband characteristics make it an ideal choice for a wide range of EMI testing applications, including demonstrating compliance with FCC, CE, MIL-STD, RTCADO-160, and other requirements.

Description

Biconical Antenna Overview:

Biconical antenna is a vertically polarized omnidirectional antenna. Its frequency range is 3 GHz to 18 GHz. its pattern stability is better. Biconical antenna model OBC-30180-10W-1 is used for transmission and immunity test to meet various EMC standards. Its broadband characteristics make it an ideal choice for a wide range of EMI testing applications, including demonstrating compliance with FCC, CE, MIL-STD, RTCADO-160, and other requirements.

OBC-30180-10W-1 biconical EMC broadband antenna has a durable aluminum alloy, and we powder coated them to improve corrosion resistance. The OBC-30180-10W-1 model is used for radiation and immunity testing to meet various EMC standards. Its frequency range is 3 GHz to18 GHz. The broadband characteristic of the biconical antenna makes it an ideal choice for scanning measurement and automatic measurement systems.

Biconical antennas can be used for many applications, in which half-wave dipoles have been used traditionally. An enormous reduction of measurement time can be achieved because the time-consuming tuning of the antenna elements to the half-wavelength is not needed, an important condition for swept broadband measurements. In typical dipole applications, several discrete frequencies are measured, in contrast, the biconical antenna allows continuous sweeps, where site anomalies are discovered much easier.

Notwithstanding the above applications, the OBC-30180-10W-1 can also be used for test site comparisons, shielding effectiveness tests of large enclosures, field monitoring, site surveys, and other general purposes.

SPEC

Electrical Specifications

3 GHz to 18 GHz, N Female

OBC-30180-10W-1

Property

Value

Min. Frequency (GHz)

3

Max. Frequency (GHz)

18

Impedance (?)

50

Power Handling (W)

10

Balun Type Transform Ratio

1:1

Connection Type

N Female

Features

Low Return Loss

Linear gain with frequency

EMC and EMI testing

Radio Link Testing

Applications

Broadband RX-Antenna for Emission Testing

TX-Antenna for Immunity testing

Specially designed at low frequencies

PDF

Outline

Biconical Antenna 3000 MHz to 18000 MHz for EMI/EMC Testing
