Rf echo Absorptive Coaxial Mechanical Switch is an active microwave device, and its frequency range from 0.8GHz to 1.5GHz . our Absorptive Coaxial Mechanical Switch has Magnetic latching, Operating life of 1 million cycles, etc.

Rf echo Absorptive Coaxial Mechanical Switch is commonly used in Wireless Infrastructure, RF Microwave & VSAT, 5G communicationFiber Optics, Test and measurement Instrument and other applications.

SKU: OSR0100800150A Categories: Routing, SPST, Switch
Add to Wishlist

Description









Additional information

Min. Frequency (GHz)

0.8
Max. Frequency (GHz)

1.5
VSWR (Max.)

1.3
Switch Type

SPST
RF Input Power (W)

50
Insertion Loss (dB)

1
