Ultra Wide Band Low Noise Amplifier From 0.05GHz to 20GHz With a Nominal 27dB Gain NF 2.5dB SMA Connectors

Ultra Wide Band Low Noise Amplifier From 0.05GHz to 20GHz With a Nominal 27dB Gain NF 2.5dB SMA Connectors

0 out of 5

• Gain: 28dB Typical
• Noise Figure: 2.0dB Typical
• P1dB Output Power: +23dBm Typical
• Supply Voltage: +12V
• 50 Ohm Matched

SKU: OLNA200052000G Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain: 28dB Typical
• Noise Figure: 2.0dB Typical
• P1dB Output Power: +23dBm Typical
• Supply Voltage: +12V
• 50 Ohm Matched



Data Sheet ( Download Datasheet PDF )

202-OLNA200052000G



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

0.05

Max. Pass Band Frequency (GHz)

20

Gain (dB)

27

NF (dB)

2.5

P1dB (dBm)

21

IP3 (dBm)

30

VSWR

1.8

"Voltage (VDC)"

12

"Current (mA)"

260

Connection Type

SMA
