Ultra Wide Band Low Noise Amplifier From 1GHz to 16GHz With a Nominal 27.5dB Gain NF 1.8dB SMA Connectors

Ultra Wide Band Low Noise Amplifier From 1GHz to 16GHz With a Nominal 27.5dB Gain NF 1.8dB SMA Connectors

0 out of 5

• Gain: 47dB Typical
• Noise Figure: 1.6dB Typical
• P1dB Output Power: 25dBm Typical
• Supply Voltage: +12V @ 350mA
• 50 Ohm Matched Input / Output
• Size: 2.92” x 1.58” x 0.47”

SKU: OLNA301001600A Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain: 47dB Typical
• Noise Figure: 1.6dB Typical
• P1dB Output Power: 25dBm Typical
• Supply Voltage: +12V @ 350mA
• 50 Ohm Matched Input / Output
• Size: 2.92” x 1.58” x 0.47”



Data Sheet ( Download Datasheet PDF )

018-OLNA301001600A



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

1

Max. Pass Band Frequency (GHz)

16

Gain (dB)

27.5

NF (dB)

1.8

P1dB (dBm)

19

IP3 (dBm)

23

VSWR

2

"Voltage (VDC)"

12

"Current (mA)"

220

Connection Type

SMA
