Ultra Wide Band Low Noise Amplifier From 2GHz to 18GHz With a Nominal 29dB Gain NF 4dB SMA Connectors

Ultra Wide Band Low Noise Amplifier From 2GHz to 18GHz With a Nominal 29dB Gain NF 4dB SMA Connectors

0 out of 5

• Gain: 29dB Typical
• Noise Figure:2.5dB Typical
• P1dB Output Power: +26dBm Typical
• Supply Voltage: +12V/300mA

SKU: OLNA402001800A Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain: 29dB Typical
• Noise Figure:2.5dB Typical
• P1dB Output Power: +26dBm Typical
• Supply Voltage: +12V/300mA



Data Sheet ( Download Datasheet PDF )

024-OLNA402001800A



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

2

Max. Pass Band Frequency (GHz)

18

Gain (dB)

29

NF (dB)

4

P1dB (dBm)

24

IP3 (dBm)

28

VSWR

1.6

"Voltage (VDC)"

12

"Current (mA)"

330

Connection Type

SMA
