Ultra Wide Band Low Noise Amplifier From 3.3GHz to 4.9GHz With a Nominal 60dB Gain NF 1.6dB WR229/N-F Connectors

Ultra Wide Band Low Noise Amplifier From 3.3GHz to 4.9GHz With a Nominal 60dB Gain NF 1.6dB WR229/N-F Connectors

0 out of 5

• Gain: 60dB Typical
• Noise Figure: 2.2dB Typical
• P1dB Output Power: +18dBm Typical
• 50 Ohm Matched

SKU: OLNA103300490A Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain: 60dB Typical
• Noise Figure: 2.2dB Typical
• P1dB Output Power: +18dBm Typical
• 50 Ohm Matched



Data Sheet ( Download Datasheet PDF )

201-OLNA103300490A



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

3.3

Max. Pass Band Frequency (GHz)

4.9

Gain (dB)

60

NF (dB)

1.6

P1dB (dBm)

19

IP3 (dBm)

30

VSWR

1.5

"Voltage (VDC)"

12

"Current (mA)"

250

Connection Type

WR229/N-F
