Band Pass Filter From 23.65~24.65GHz OBP-24150-1000 With SMA-Female Connectors

Ocean Microwave band-pass filter (Ocean band-pass filter,abbreviation:abbreviation:OBP) is a filter that allows waves of specific frequencybandto pass through while rejecting other frequency bands.

The product name of this Ocean band-pass filter (OBP) is OBP-24150-1000, its Center Frequency(F0) is 24.15GHz, it’s Pass Band Bandwidth is 23.65~24.65GHz,its Pass Band Insertion Loss is ≤0.8dB, Pass Band VSWR is ≤1.33:1, and the Stop Band frequency is ≥65dB @DC~21.2GHz ≥65dB @27.1~47GHz.

Availability: Available on backorder SKU: OBP-24150-1000 Categories: Cavity Band Pass Filter, RF Cavity Filter, RF Filters

Description

Ocean Microwave band-pass filter (Ocean band-pass filter,abbreviation:abbreviation:OBP) is a filter that allows waves of specific frequencybandto pass through while rejecting other frequency bands.

The product name of this Ocean band-pass filter (OBP) is OBP-24150-1000, its Center Frequency(F0) is 24.15GHz, it’s Pass Band Bandwidth is 23.65~24.65GHz,its Pass Band Insertion Loss is ≤0.8dB, Pass Band VSWR is ≤1.33:1, and the Stop Band frequency is ≥65dB @DC~21.2GHz ≥65dB @27.1~47GHz.

Band Pass Filter Datasheet (Click to download)

Additional information

Center Frequency (F0) (MHz)

24150

Min. Pass Band Frequency (MHz)

23650

Max. Pass Band Frequency (MHz)

24650

Pass Band Insertion Loss (dB)

≤0.8dB ≤0.2dB ≥20dB

Stop Band Rejection

≥65dB @ DC ~ 21.2GHz ≥65dB @ 27.1 ~ 47GHz

Impedance (Ω)

50

Power Handling (W)

5W Max

Connection Type

SMA-Female
