Band Recject Filter From 1880MHz To 1930MHz With SMA-Female Connectors

Band Recject Filter From 1880MHz To 1930MHz With SMA-Female Connectors

Ocean Microwave Bandstop Filters (Ocean Bandstop Filters,abbreviation:OBR) refer to filters that can pass through most frequency but attenuate some range of frequency to extremely low levels, which is opposite to the concept of band-pass filters. Among them, the notch filter is a special band-stop filter with a very small stop band range and a very high Q Factor.
The product name of this Ocean Bandstop Filters (OBR) is OBR-1905-50,its Stop Band Frequency is 1.88.4-1.93GHz,Stop Band attenuation is 40dB,its Pass Band Frequency is
DC-1.83GHz&1.98-4.6GHz, and its Pass Band Insertion Loss is 1.5dB. Its Pass Band VSWR is 1.4.

SKU: OBR-1905-50 Categories: Cavity Band Reject Filter, RF Cavity Filter, RF Filters

Description

OBR-1905-50 band-reject filter (also called a band-stop filter or notch filter in narrow stopband) from RFecho is just part of a wide selection of coaxial RF filter products supplied. This RF band reject filter is built from 1880MHz to 1930MHz with SMA Female connectors. The SMA band-reject filter design is rated for a VSWR of 1.5:1 and a maximum power of 50 Watts.

RFecho band-reject / band-stop filters have a minimum stopband frequency of 200 MHz and a maximum stopband frequency of 18GHz. The band-stop / notch filter part number OBR-1905-50 has an insertion loss maximum that is 1.5 dB. More RF coaxial band-stop / notch filter specs for this radio frequency component can be found on its notch/rejection RF filter PDF specifications datasheet.

RFecho also stocks a large selection of other band-stop RF filter products that will ship the same day from our location. RF/microwave and millimeter wave cavity filter components and other RF parts for radio, antenna, other types of radio frequency component connections in typical use, production, test and measurement labs, military/defense, etc. are in stock and ship same day from our warehouse inventory.



Band Reject Filter Datasheet (Click to download)

OBR-1905-50

Additional information

Center Frequency (F0) (MHz)

NA

Stop Band Min. Frequency (MHz)

1880

Stop Band Max. Frequency (MHz)

1930

Stop Band Attenuation (dB)

≥40

Band Min. Frequency (MHz) A

DC

Band Max. Frequency (MHz) A

1830

Band Min. Frequency (MHz) B

1980

Band Max. Frequency (MHz) B

4600

Pass Band Insertion Loss (dB)

≤1.5

Impedance (Ω)

50

Power Handling (W)

≤50

Connection Type

SMA-Female
