Ultra Wide Band Low Noise Amplifier From 0.01GHz to 20GHz With a Nominal 28dB Gain NF 3dB SMA-Female Connectors

Ultra Wide Band Low Noise Amplifier From 0.01GHz to 20GHz With a Nominal 28dB Gain NF 3dB SMA-Female Connectors

0 out of 5

• High Output Power 23dBmTypical.
• High peak to average handling capability.
• High linearity and low noise figure.
• Convenient AC Power Input. (AC 110V/220V)
• Integrated Heat Sink and Fan.

SKU: OACLA00012000A Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• High Output Power 23dBmTypical.
• High peak to average handling capability.
• High linearity and low noise figure.
• Convenient AC Power Input. (AC 110V/220V)
• Integrated Heat Sink and Fan.



Data Sheet ( Download Datasheet PDF )

112-OACLA00012000A



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

0.01

Max. Pass Band Frequency (GHz)

20

Gain (dB)

28

NF (dB)

3

P1dB (dBm)

21

IP3 (dBm)

26

VSWR

2

"Voltage (VDC)"

110-220V

"Current (mA)"

55

Connection Type

SMA-Female
