Ultra Wide Band Low Noise Amplifier From 0.05GHz to 20GHz With a Nominal 28dB Gain NF 1.8dB SMA Connectors

Ultra Wide Band Low Noise Amplifier From 0.05GHz to 20GHz With a Nominal 28dB Gain NF 1.8dB SMA Connectors

0 out of 5

• Gain: 28dB Typical
• Noise Figure: 1.8dB Typical
• P1dB Output Power: 16dBm Typical
• Supply Voltage: +12V @ 130mA
• 50 Ohm Matched Input / Output
• Size: 1.18” x 1.57” x0.39”

SKU: OLNA200052000F Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain: 28dB Typical
• Noise Figure: 1.8dB Typical
• P1dB Output Power: 16dBm Typical
• Supply Voltage: +12V @ 130mA
• 50 Ohm Matched Input / Output
• Size: 1.18” x 1.57” x0.39”



Data Sheet ( Download Datasheet PDF )

141-OLNA200052000F



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

0.05

Max. Pass Band Frequency (GHz)

20

Gain (dB)

28

NF (dB)

1.8

P1dB (dBm)

18

IP3 (dBm)

28

VSWR

2

"Voltage (VDC)"

12

"Current (mA)"

150

Connection Type

SMA
