Ultra Wide Band Low Noise Amplifier From 0.1GHz to 10GHz With a Nominal 30dB Gain NF 2.5dB SMA Connectors

Ultra Wide Band Low Noise Amplifier From 0.1GHz to 10GHz With a Nominal 30dB Gain NF 2.5dB SMA Connectors

• Gain: 30 dB Typical
• Noise Figure: 2.5dB Typical
• P1dB Output Power: +25dBm Typical
• Supply Voltage: +12V @ 320mA
• 50 Ohm Matched Input / Output
• Size: 1.18” x 1.58” x 0.39”

SKU: OLNA300101000B Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain: 30 dB Typical
• Noise Figure: 2.5dB Typical
• P1dB Output Power: +25dBm Typical
• Supply Voltage: +12V @ 320mA
• 50 Ohm Matched Input / Output
• Size: 1.18” x 1.58” x 0.39”



Data Sheet ( Download Datasheet PDF )

133-OLNA300101000B



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

0.1

Max. Pass Band Frequency (GHz)

10

Gain (dB)

30

NF (dB)

2.5

P1dB (dBm)

26

IP3 (dBm)

35

VSWR

2

"Voltage (VDC)"

12

"Current (mA)"

320

Connection Type

SMA
