Ultra Wide Band Low Noise Amplifier From 0.1GHz to 15GHz With a Nominal 31dB Gain NF 4dB SMA-M/F Connectors

Ultra Wide Band Low Noise Amplifier From 0.1GHz to 15GHz With a Nominal 31dB Gain NF 4dB SMA-M/F Connectors

0 out of 5

• Gain: 31dB Typical
• Functional Bandwidth : 0.1GHz to 15 GHz
• Noise Figure: 4.0dB Typical
• P1dB Output Power: +25dBm Typical
• Supply Voltage: +12V

SKU: OLNA400100650A Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain: 31dB Typical
• Functional Bandwidth : 0.1GHz to 15 GHz
• Noise Figure: 4.0dB Typical
• P1dB Output Power: +25dBm Typical
• Supply Voltage: +12V



Data Sheet ( Download Datasheet PDF )

152-OLNA400100650A



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

0.1

Max. Pass Band Frequency (GHz)

15

Gain (dB)

31

NF (dB)

4

P1dB (dBm)

25

IP3 (dBm)

35

VSWR

1.35

"Voltage (VDC)"

12

"Current (mA)"

330

Connection Type

SMA-M/F
