Ultra Wide Band Low Noise Amplifier From 0.1GHz to 20GHz With a Nominal 33dB Gain NF 2.8dB SMA Connectors

Ultra Wide Band Low Noise Amplifier From 0.1GHz to 20GHz With a Nominal 33dB Gain NF 2.8dB SMA Connectors

0 out of 5

• Gain: 33dB Typical
• Functional Bandwidth : 0.1GHz to 20GHz
• Noise Figure: 2.2dB Typical
• P1dB Output Power: +26dBm Typical
• Supply Voltage: +12V

SKU: OLNA200101000C Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain: 33dB Typical
• Functional Bandwidth : 0.1GHz to 20GHz
• Noise Figure: 2.2dB Typical
• P1dB Output Power: +26dBm Typical
• Supply Voltage: +12V



Data Sheet ( Download Datasheet PDF )

140-OLNA200101000C



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

0.1

Max. Pass Band Frequency (GHz)

20

Gain (dB)

33

NF (dB)

2.8

P1dB (dBm)

22

IP3 (dBm)

32

VSWR

1.8

"Voltage (VDC)"

12

"Current (mA)"

320

Connection Type

SMA
