Ultra Wide Band Low Noise Amplifier From 0.1GHz to 50GHz With a Nominal 38dB Gain NF 4.5dB 2.4mm Connectors

Ultra Wide Band Low Noise Amplifier From 0.1GHz to 50GHz With a Nominal 38dB Gain NF 4.5dB 2.4mm Connectors

0 out of 5

Low noise figure 5.0 Typical
• Output Power: +20dBm Typical .
• Microwave Radio and VSAT.
• TelecomInfrastructure Applications.
• High peak to average handling capability.
• High linearity and low noise figure.
• Convenient AC Power Input.
• Integrated Heat Sink and Fan.
• All specifications can be modified upon request

SKU: OACLA00105000A Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

Low noise figure 5.0 Typical
• Output Power: +20dBm Typical .
• Microwave Radio and VSAT.
• TelecomInfrastructure Applications.
• High peak to average handling capability.
• High linearity and low noise figure.
• Convenient AC Power Input.
• Integrated Heat Sink and Fan.
• All specifications can be modified upon request



Data Sheet ( Download Datasheet PDF )

143-OACLA00105000A



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

0.1

Max. Pass Band Frequency (GHz)

50

Gain (dB)

38

NF (dB)

4.5

P1dB (dBm)

19

IP3 (dBm)

28

VSWR

1.3

"Voltage (VDC)"

110-220V

"Current (mA)"

550

Connection Type

2.4mm
