Ultra Wide Band Low Noise Amplifier From 1.1GHz to 1.9GHz With a Nominal 34dB Gain NF 1.3dB SMA Connectors

Ultra Wide Band Low Noise Amplifier From 1.1GHz to 1.9GHz With a Nominal 34dB Gain NF 1.3dB SMA Connectors

0 out of 5

• Gain:34dB Typical
• Noise Figure: 1.3dB Typical
• P1dB Output Power: +20dBm Typical
• Supply Voltage: +12V @ 190mA
• 50 Ohm Matched

SKU: OLNA101100170A Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain:34dB Typical
• Noise Figure: 1.3dB Typical
• P1dB Output Power: +20dBm Typical
• Supply Voltage: +12V @ 190mA
• 50 Ohm Matched



Data Sheet ( Download Datasheet PDF )

030-OLNA101100170A



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

1.1

Max. Pass Band Frequency (GHz)

1.9

Gain (dB)

34

NF (dB)

1.3

P1dB (dBm)

20

IP3 (dBm)

35

VSWR

1.5

"Voltage (VDC)"

12

"Current (mA)"

190

Connection Type

SMA
