Ultra Wide Band Low Noise Amplifier From 18GHz to 20.9GHz With a Nominal 34dB Gain NF 2.7dB SMA Connectors

Ultra Wide Band Low Noise Amplifier From 18GHz to 20.9GHz With a Nominal 34dB Gain NF 2.7dB SMA Connectors

0 out of 5

• Gain: 35dBtypical
• Noise Figure:1.8dB typical
• High P1dB: +21dBmtypical
• Supply Voltage: +12V @ 160mA
• 50 Ohm Matched

SKU: OLNA318002090A Categories: Low Noise Amplifier, Passive Devices

Description

Key Specifications

• Gain: 35dBtypical
• Noise Figure:1.8dB typical
• High P1dB: +21dBmtypical
• Supply Voltage: +12V @ 160mA
• 50 Ohm Matched



Data Sheet ( Download Datasheet PDF )

059-OLNA318002090A



Applications

• Wireless Infrastructure
• RF Microwave & VSAT
• 5G communicationFiber Optics
• Test and measurement Instrument

Additional information

Min. Pass Band Frequency (GHz)

18

Max. Pass Band Frequency (GHz)

20.9

Gain (dB)

34

NF (dB)

2.7

P1dB (dBm)

20

IP3 (dBm)

22

VSWR

1.5

"Voltage (VDC)"

12

"Current (mA)"

250

Connection Type

SMA
