CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor

Filterable Table

SKU	Rated Voltage (Ur) (V)	Surge Voltage (Us) (V)	Capacitance (CR) (uF)	Case Size(mm)	Case Type	Dimensions
CAK36C-10-3000-K-CA1-A	10	11	3000	φ12 × 8 mm	A	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-10-3000-K-CA1-B	10	11	3000	φ12 × 8 mm	B	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-10-3000-K-CA1-C	10	11	3000	φ12 × 8 mm	C	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-10-3600-K-CA2-A	10	11	3600	φ12 × 10 mm	A	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-10-3600-K-CA2-B	10	11	3600	φ12 × 10 mm	B	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-10-3600-K-CA2-C	10	11	3600	φ12 × 10 mm	C	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-10-6000-K-CA3-A	10	11	6000	φ12 × 12 mm	A	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-10-6000-K-CA3-B	10	11	6000	φ12 × 12 mm	B	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-10-6000-K-CA3-C	10	11	6000	φ12 × 12 mm	C	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-10-6000-K-CB1-A	10	11	6000	φ16 × 8 mm	A	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-6000-K-CB1-B	10	11	6000	φ16 × 8 mm	B	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-6000-K-CB1-C	10	11	6000	φ16 × 8 mm	C	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-8000-K-CB2-A	10	11	8000	φ16 × 10 mm	A	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-8000-K-CB2-B	10	11	8000	φ16 × 10 mm	B	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-8000-K-CB2-C	10	11	8000	φ16 × 10 mm	C	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-12000-K-CB3-A	10	11	12000	φ16 × 12 mm	A	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-12000-K-CB3-B	10	11	12000	φ16 × 12 mm	B	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-12000-K-CB3-C	10	11	12000	φ16 × 12 mm	C	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-18000-K-CB4-A	10	11	18000	φ16 × 16 mm	A	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-18000-K-CB4-B	10	11	18000	φ16 × 16 mm	B	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-18000-K-CB4-C	10	11	18000	φ16 × 16 mm	C	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-10-12000-K-CD1-A	10	11	12000	φ22 × 8 mm	A	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-12000-K-CD1-B	10	11	12000	φ22 × 8 mm	B	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-12000-K-CD1-C	10	11	12000	φ22 × 8 mm	C	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-12000-K-CD1-BL	10	11	12000	φ22 × 8 mm	BL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-12000-K-CD1-CL	10	11	12000	φ22 × 8 mm	CL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-16000-K-CD2-A	10	11	16000	φ22 × 10 mm	A	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-16000-K-CD2-B	10	11	16000	φ22 × 10 mm	B	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-16000-K-CD2-C	10	11	16000	φ22 × 10 mm	C	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-16000-K-CD2-BL	10	11	16000	φ22 × 10 mm	BL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-16000-K-CD2-CL	10	11	16000	φ22 × 10 mm	CL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-24000-K-CD3-A	10	11	24000	φ22 × 12 mm	A	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-24000-K-CD3-B	10	11	24000	φ22 × 12 mm	B	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-24000-K-CD3-C	10	11	24000	φ22 × 12 mm	C	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-24000-K-CD3-BL	10	11	24000	φ22 × 12 mm	BL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-24000-K-CD3-CL	10	11	24000	φ22 × 12 mm	CL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-36000-K-CD4-A	10	11	36000	φ22 × 16 mm	A	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-36000-K-CD4-B	10	11	36000	φ22 × 16 mm	B	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-36000-K-CD4-C	10	11	36000	φ22 × 16 mm	C	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-36000-K-CD4-BL	10	11	36000	φ22 × 16 mm	BL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-36000-K-CD4-CL	10	11	36000	φ22 × 16 mm	CL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD5-A	10	11	48000	φ22 × 18 mm	A	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD5-B	10	11	48000	φ22 × 18 mm	B	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD5-C	10	11	48000	φ22 × 18 mm	C	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD5-BL	10	11	48000	φ22 × 18 mm	BL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD5-CL	10	11	48000	φ22 × 18 mm	CL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD6-A	10	11	48000	φ22 × 20 mm	A	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD6-B	10	11	48000	φ22 × 20 mm	B	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD6-C	10	11	48000	φ22 × 20 mm	C	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD6-BL	10	11	48000	φ22 × 20 mm	BL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-48000-K-CD6-CL	10	11	48000	φ22 × 20 mm	CL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-10-40000-K-CE1-A	10	11	40000	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-40000-K-CE1-B	10	11	40000	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-40000-K-CE1-C	10	11	40000	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-40000-K-CE1-BL	10	11	40000	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-40000-K-CE1-CL	10	11	40000	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-50000-K-CE2-A	10	11	50000	φ36 × 10 mm	A	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-50000-K-CE2-B	10	11	50000	φ36 × 10 mm	B	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-50000-K-CE2-C	10	11	50000	φ36 × 10 mm	C	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-50000-K-CE2-BL	10	11	50000	φ36 × 10 mm	BL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-50000-K-CE2-CL	10	11	50000	φ36 × 10 mm	CL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-80000-K-CE3-A	10	11	80000	φ36 × 12 mm	A	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-80000-K-CE3-B	10	11	80000	φ36 × 12 mm	B	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-80000-K-CE3-C	10	11	80000	φ36 × 12 mm	C	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-80000-K-CE3-BL	10	11	80000	φ36 × 12 mm	BL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-10-80000-K-CE3-CL	10	11	80000	φ36 × 12 mm	CL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-1500-K-CA1-A	16	17.6	1500	φ12 × 8 mm	A	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-16-1500-K-CA1-B	16	17.6	1500	φ12 × 8 mm	B	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-16-1500-K-CA1-C	16	17.6	1500	φ12 × 8 mm	C	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-16-1800-K-CA2-A	16	17.6	1800	φ12 × 10 mm	A	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-16-1800-K-CA2-B	16	17.6	1800	φ12 × 10 mm	B	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-16-1800-K-CA2-C	16	17.6	1800	φ12 × 10 mm	C	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-16-3000-K-CA3-A	16	17.6	3000	φ12 × 12 mm	A	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-16-3000-K-CA3-B	16	17.6	3000	φ12 × 12 mm	B	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-16-3000-K-CA3-C	16	17.6	3000	φ12 × 12 mm	C	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-16-4000-K-CB1-A	16	17.6	4000	φ16 × 8 mm	A	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-4000-K-CB1-B	16	17.6	4000	φ16 × 8 mm	B	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-4000-K-CB1-C	16	17.6	4000	φ16 × 8 mm	C	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-5000-K-CB2-A	16	17.6	5000	φ16 × 10 mm	A	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-5000-K-CB2-B	16	17.6	5000	φ16 × 10 mm	B	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-5000-K-CB2-C	16	17.6	5000	φ16 × 10 mm	C	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-8000-K-CB3-A	16	17.6	8000	φ16 × 12 mm	A	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-8000-K-CB3-B	16	17.6	8000	φ16 × 12 mm	B	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-8000-K-CB3-C	16	17.6	8000	φ16 × 12 mm	C	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-12000-K-CB4-A	16	17.6	12000	φ16 × 16 mm	A	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-12000-K-CB4-B	16	17.6	12000	φ16 × 16 mm	B	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-12000-K-CB4-C	16	17.6	12000	φ16 × 16 mm	C	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-16-7500-K-CD1-A	16	17.6	7500	φ22 × 8 mm	A	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-7500-K-CD1-B	16	17.6	7500	φ22 × 8 mm	B	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-7500-K-CD1-C	16	17.6	7500	φ22 × 8 mm	C	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-7500-K-CD1-BL	16	17.6	7500	φ22 × 8 mm	BL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-7500-K-CD1-CL	16	17.6	7500	φ22 × 8 mm	CL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-10000-K-CD2-A	16	17.6	10000	φ22 × 10 mm	A	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-10000-K-CD2-B	16	17.6	10000	φ22 × 10 mm	B	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-10000-K-CD2-C	16	17.6	10000	φ22 × 10 mm	C	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-10000-K-CD2-BL	16	17.6	10000	φ22 × 10 mm	BL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-10000-K-CD2-CL	16	17.6	10000	φ22 × 10 mm	CL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-15000-K-CD3-A	16	17.6	15000	φ22 × 12 mm	A	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-15000-K-CD3-B	16	17.6	15000	φ22 × 12 mm	B	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-15000-K-CD3-C	16	17.6	15000	φ22 × 12 mm	C	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-15000-K-CD3-BL	16	17.6	15000	φ22 × 12 mm	BL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-15000-K-CD3-CL	16	17.6	15000	φ22 × 12 mm	CL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-22500-K-CD4-A	16	17.6	22500	φ22 × 16 mm	A	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-22500-K-CD4-B	16	17.6	22500	φ22 × 16 mm	B	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-22500-K-CD4-C	16	17.6	22500	φ22 × 16 mm	C	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-22500-K-CD4-BL	16	17.6	22500	φ22 × 16 mm	BL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-22500-K-CD4-CL	16	17.6	22500	φ22 × 16 mm	CL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD5-A	16	17.6	30000	φ22 × 18 mm	A	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD5-B	16	17.6	30000	φ22 × 18 mm	B	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD5-C	16	17.6	30000	φ22 × 18 mm	C	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD5-BL	16	17.6	30000	φ22 × 18 mm	BL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD5-CL	16	17.6	30000	φ22 × 18 mm	CL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD6-A	16	17.6	30000	φ22 × 20 mm	A	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD6-B	16	17.6	30000	φ22 × 20 mm	B	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD6-C	16	17.6	30000	φ22 × 20 mm	C	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD6-BL	16	17.6	30000	φ22 × 20 mm	BL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-30000-K-CD6-CL	16	17.6	30000	φ22 × 20 mm	CL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-16-24000-K-CE1-A	16	17.6	24000	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-24000-K-CE1-B	16	17.6	24000	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-24000-K-CE1-C	16	17.6	24000	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-24000-K-CE1-BL	16	17.6	24000	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-24000-K-CE1-CL	16	17.6	24000	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-30000-K-CE2-A	16	17.6	30000	φ36 × 10 mm	A	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-30000-K-CE2-B	16	17.6	30000	φ36 × 10 mm	B	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-30000-K-CE2-C	16	17.6	30000	φ36 × 10 mm	C	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-30000-K-CE2-BL	16	17.6	30000	φ36 × 10 mm	BL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-30000-K-CE2-CL	16	17.6	30000	φ36 × 10 mm	CL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-48000-K-CE3-A	16	17.6	48000	φ36 × 12 mm	A	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-48000-K-CE3-B	16	17.6	48000	φ36 × 12 mm	B	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-48000-K-CE3-C	16	17.6	48000	φ36 × 12 mm	C	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-48000-K-CE3-BL	16	17.6	48000	φ36 × 12 mm	BL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-48000-K-CE3-CL	16	17.6	48000	φ36 × 12 mm	CL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-72000-K-CE4-A	16	17.6	72000	φ36 × 16 mm	A	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-72000-K-CE4-B	16	17.6	72000	φ36 × 16 mm	B	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-72000-K-CE4-C	16	17.6	72000	φ36 × 16 mm	C	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-72000-K-CE4-BL	16	17.6	72000	φ36 × 16 mm	BL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-72000-K-CE4-CL	16	17.6	72000	φ36 × 16 mm	CL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-90000-K-CE5-A	16	17.6	90000	φ36 × 18 mm	A	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-90000-K-CE5-B	16	17.6	90000	φ36 × 18 mm	B	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-90000-K-CE5-C	16	17.6	90000	φ36 × 18 mm	C	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-90000-K-CE5-BL	16	17.6	90000	φ36 × 18 mm	BL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-90000-K-CE5-CL	16	17.6	90000	φ36 × 18 mm	CL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-96000-K-CE6-A	16	17.6	96000	φ36 × 20 mm	A	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-96000-K-CE6-B	16	17.6	96000	φ36 × 20 mm	B	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-96000-K-CE6-C	16	17.6	96000	φ36 × 20 mm	C	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-96000-K-CE6-BL	16	17.6	96000	φ36 × 20 mm	BL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-16-96000-K-CE6-CL	16	17.6	96000	φ36 × 20 mm	CL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-1200-K-CA1-A	25	27.5	1200	φ12 × 8 mm	A	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-25-1200-K-CA1-B	25	27.5	1200	φ12 × 8 mm	B	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-25-1200-K-CA1-C	25	27.5	1200	φ12 × 8 mm	C	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-25-1500-K-CA2-A	25	27.5	1500	φ12 × 10 mm	A	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-25-1500-K-CA2-B	25	27.5	1500	φ12 × 10 mm	B	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-25-1500-K-CA2-C	25	27.5	1500	φ12 × 10 mm	C	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-25-2400-K-CA3-A	25	27.5	2400	φ12 × 12 mm	A	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-25-2400-K-CA3-B	25	27.5	2400	φ12 × 12 mm	B	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-25-2400-K-CA3-C	25	27.5	2400	φ12 × 12 mm	C	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-25-2500-K-CB1-A	25	27.5	2500	φ16 × 8 mm	A	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-2500-K-CB1-B	25	27.5	2500	φ16 × 8 mm	B	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-2500-K-CB1-C	25	27.5	2500	φ16 × 8 mm	C	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-3000-K-CB2-A	25	27.5	3000	φ16 × 10 mm	A	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-3000-K-CB2-B	25	27.5	3000	φ16 × 10 mm	B	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-3000-K-CB2-C	25	27.5	3000	φ16 × 10 mm	C	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-5000-K-CB3-A	25	27.5	5000	φ16 × 12 mm	A	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-5000-K-CB3-B	25	27.5	5000	φ16 × 12 mm	B	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-5000-K-CB3-C	25	27.5	5000	φ16 × 12 mm	C	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-7500-K-CB4-A	25	27.5	7500	φ16 × 16 mm	A	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-7500-K-CB4-B	25	27.5	7500	φ16 × 16 mm	B	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-7500-K-CB4-C	25	27.5	7500	φ16 × 16 mm	C	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-25-4500-K-CD1-A	25	27.5	4500	φ22 × 8 mm	A	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-4500-K-CD1-B	25	27.5	4500	φ22 × 8 mm	B	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-4500-K-CD1-C	25	27.5	4500	φ22 × 8 mm	C	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-4500-K-CD1-BL	25	27.5	4500	φ22 × 8 mm	BL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-4500-K-CD1-CL	25	27.5	4500	φ22 × 8 mm	CL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-6000-K-CD2-A	25	27.5	6000	φ22 × 10 mm	A	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-6000-K-CD2-B	25	27.5	6000	φ22 × 10 mm	B	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-6000-K-CD2-C	25	27.5	6000	φ22 × 10 mm	C	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-6000-K-CD2-BL	25	27.5	6000	φ22 × 10 mm	BL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-6000-K-CD2-CL	25	27.5	6000	φ22 × 10 mm	CL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-9000-K-CD3-A	25	27.5	9000	φ22 × 12 mm	A	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-9000-K-CD3-B	25	27.5	9000	φ22 × 12 mm	B	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-9000-K-CD3-C	25	27.5	9000	φ22 × 12 mm	C	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-9000-K-CD3-BL	25	27.5	9000	φ22 × 12 mm	BL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-9000-K-CD3-CL	25	27.5	9000	φ22 × 12 mm	CL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-13500-K-CD4-A	25	27.5	13500	φ22 × 16 mm	A	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-13500-K-CD4-B	25	27.5	13500	φ22 × 16 mm	B	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-13500-K-CD4-C	25	27.5	13500	φ22 × 16 mm	C	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-13500-K-CD4-BL	25	27.5	13500	φ22 × 16 mm	BL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-13500-K-CD4-CL	25	27.5	13500	φ22 × 16 mm	CL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD5-A	25	27.5	18000	φ22 × 18 mm	A	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD5-B	25	27.5	18000	φ22 × 18 mm	B	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD5-C	25	27.5	18000	φ22 × 18 mm	C	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD5-BL	25	27.5	18000	φ22 × 18 mm	BL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD5-CL	25	27.5	18000	φ22 × 18 mm	CL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD6-A	25	27.5	18000	φ22 × 20 mm	A	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD6-B	25	27.5	18000	φ22 × 20 mm	B	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD6-C	25	27.5	18000	φ22 × 20 mm	C	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD6-BL	25	27.5	18000	φ22 × 20 mm	BL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-18000-K-CD6-CL	25	27.5	18000	φ22 × 20 mm	CL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-25-15000-K-CE1-A	25	27.5	15000	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-15000-K-CE1-B	25	27.5	15000	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-15000-K-CE1-C	25	27.5	15000	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-15000-K-CE1-BL	25	27.5	15000	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-15000-K-CE1-CL	25	27.5	15000	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-18000-K-CE2-A	25	27.5	18000	φ36 × 10 mm	A	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-18000-K-CE2-B	25	27.5	18000	φ36 × 10 mm	B	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-18000-K-CE2-C	25	27.5	18000	φ36 × 10 mm	C	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-18000-K-CE2-BL	25	27.5	18000	φ36 × 10 mm	BL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-18000-K-CE2-CL	25	27.5	18000	φ36 × 10 mm	CL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-30000-K-CE3-A	25	27.5	30000	φ36 × 12 mm	A	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-30000-K-CE3-B	25	27.5	30000	φ36 × 12 mm	B	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-30000-K-CE3-C	25	27.5	30000	φ36 × 12 mm	C	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-30000-K-CE3-BL	25	27.5	30000	φ36 × 12 mm	BL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-30000-K-CE3-CL	25	27.5	30000	φ36 × 12 mm	CL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-45000-K-CE4-A	25	27.5	45000	φ36 × 16 mm	A	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-45000-K-CE4-B	25	27.5	45000	φ36 × 16 mm	B	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-45000-K-CE4-C	25	27.5	45000	φ36 × 16 mm	C	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-45000-K-CE4-BL	25	27.5	45000	φ36 × 16 mm	BL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-45000-K-CE4-CL	25	27.5	45000	φ36 × 16 mm	CL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-54000-K-CE5-A	25	27.5	54000	φ36 × 18 mm	A	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-54000-K-CE5-B	25	27.5	54000	φ36 × 18 mm	B	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-54000-K-CE5-C	25	27.5	54000	φ36 × 18 mm	C	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-54000-K-CE5-BL	25	27.5	54000	φ36 × 18 mm	BL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-54000-K-CE5-CL	25	27.5	54000	φ36 × 18 mm	CL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-60000-K-CE6-A	25	27.5	60000	φ36 × 20 mm	A	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-60000-K-CE6-B	25	27.5	60000	φ36 × 20 mm	B	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-60000-K-CE6-C	25	27.5	60000	φ36 × 20 mm	C	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-60000-K-CE6-BL	25	27.5	60000	φ36 × 20 mm	BL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-60000-K-CE6-CL	25	27.5	60000	φ36 × 20 mm	CL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-75000-K-CE7-A	25	27.5	75000	φ36 × 24 mm	A	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-75000-K-CE7-B	25	27.5	75000	φ36 × 24 mm	B	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-75000-K-CE7-C	25	27.5	75000	φ36 × 24 mm	C	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-75000-K-CE7-BL	25	27.5	75000	φ36 × 24 mm	BL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-25-75000-K-CE7-CL	25	27.5	75000	φ36 × 24 mm	CL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-800-K-CA1-A	35	38.5	800	φ12 × 8 mm	A	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-35-800-K-CA1-B	35	38.5	800	φ12 × 8 mm	B	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-35-800-K-CA1-C	35	38.5	800	φ12 × 8 mm	C	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-35-900-K-CA2-A	35	38.5	900	φ12 × 10 mm	A	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-35-900-K-CA2-B	35	38.5	900	φ12 × 10 mm	B	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-35-900-K-CA2-C	35	38.5	900	φ12 × 10 mm	C	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-35-1600-K-CA3-A	35	38.5	1600	φ12 × 12 mm	A	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-35-1600-K-CA3-B	35	38.5	1600	φ12 × 12 mm	B	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-35-1600-K-CA3-C	35	38.5	1600	φ12 × 12 mm	C	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-35-1800-K-CB1-A	35	38.5	1800	φ16 × 8 mm	A	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-1800-K-CB1-B	35	38.5	1800	φ16 × 8 mm	B	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-1800-K-CB1-C	35	38.5	1800	φ16 × 8 mm	C	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-2500-K-CB2-A	35	38.5	2500	φ16 × 10 mm	A	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-2500-K-CB2-B	35	38.5	2500	φ16 × 10 mm	B	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-2500-K-CB2-C	35	38.5	2500	φ16 × 10 mm	C	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-3600-K-CB3-A	35	38.5	3600	φ16 × 12 mm	A	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-3600-K-CB3-B	35	38.5	3600	φ16 × 12 mm	B	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-3600-K-CB3-C	35	38.5	3600	φ16 × 12 mm	C	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-5400-K-CB4-A	35	38.5	5400	φ16 × 16 mm	A	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-5400-K-CB4-B	35	38.5	5400	φ16 × 16 mm	B	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-5400-K-CB4-C	35	38.5	5400	φ16 × 16 mm	C	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-35-4000-K-CD1-A	35	38.5	4000	φ22 × 8 mm	A	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-4000-K-CD1-B	35	38.5	4000	φ22 × 8 mm	B	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-4000-K-CD1-C	35	38.5	4000	φ22 × 8 mm	C	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-4000-K-CD1-BL	35	38.5	4000	φ22 × 8 mm	BL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-4000-K-CD1-CL	35	38.5	4000	φ22 × 8 mm	CL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-5200-K-CD2-A	35	38.5	5200	φ22 × 10 mm	A	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-5200-K-CD2-B	35	38.5	5200	φ22 × 10 mm	B	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-5200-K-CD2-C	35	38.5	5200	φ22 × 10 mm	C	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-5200-K-CD2-BL	35	38.5	5200	φ22 × 10 mm	BL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-5200-K-CD2-CL	35	38.5	5200	φ22 × 10 mm	CL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-8000-K-CD3-A	35	38.5	8000	φ22 × 12 mm	A	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-8000-K-CD3-B	35	38.5	8000	φ22 × 12 mm	B	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-8000-K-CD3-C	35	38.5	8000	φ22 × 12 mm	C	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-8000-K-CD3-BL	35	38.5	8000	φ22 × 12 mm	BL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-8000-K-CD3-CL	35	38.5	8000	φ22 × 12 mm	CL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-12000-K-CD4-A	35	38.5	12000	φ22 × 16 mm	A	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-12000-K-CD4-B	35	38.5	12000	φ22 × 16 mm	B	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-12000-K-CD4-C	35	38.5	12000	φ22 × 16 mm	C	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-12000-K-CD4-BL	35	38.5	12000	φ22 × 16 mm	BL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-12000-K-CD4-CL	35	38.5	12000	φ22 × 16 mm	CL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-15600-K-CD5-A	35	38.5	15600	φ22 × 18 mm	A	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-15600-K-CD5-B	35	38.5	15600	φ22 × 18 mm	B	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-15600-K-CD5-C	35	38.5	15600	φ22 × 18 mm	C	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-15600-K-CD5-BL	35	38.5	15600	φ22 × 18 mm	BL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-15600-K-CD5-CL	35	38.5	15600	φ22 × 18 mm	CL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-16000-K-CD6-A	35	38.5	16000	φ22 × 20 mm	A	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-16000-K-CD6-B	35	38.5	16000	φ22 × 20 mm	B	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-16000-K-CD6-C	35	38.5	16000	φ22 × 20 mm	C	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-16000-K-CD6-BL	35	38.5	16000	φ22 × 20 mm	BL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-16000-K-CD6-CL	35	38.5	16000	φ22 × 20 mm	CL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-35-9000-K-CE1-A	35	38.5	9000	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-9000-K-CE1-B	35	38.5	9000	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-9000-K-CE1-C	35	38.5	9000	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-9000-K-CE1-BL	35	38.5	9000	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-9000-K-CE1-CL	35	38.5	9000	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-12000-K-CE2-A	35	38.5	12000	φ36 × 10 mm	A	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-12000-K-CE2-B	35	38.5	12000	φ36 × 10 mm	B	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-12000-K-CE2-C	35	38.5	12000	φ36 × 10 mm	C	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-12000-K-CE2-BL	35	38.5	12000	φ36 × 10 mm	BL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-12000-K-CE2-CL	35	38.5	12000	φ36 × 10 mm	CL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-18000-K-CE3-A	35	38.5	18000	φ36 × 12 mm	A	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-18000-K-CE3-B	35	38.5	18000	φ36 × 12 mm	B	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-18000-K-CE3-C	35	38.5	18000	φ36 × 12 mm	C	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-18000-K-CE3-BL	35	38.5	18000	φ36 × 12 mm	BL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-18000-K-CE3-CL	35	38.5	18000	φ36 × 12 mm	CL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-27000-K-CE4-A	35	38.5	27000	φ36 × 16 mm	A	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-27000-K-CE4-B	35	38.5	27000	φ36 × 16 mm	B	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-27000-K-CE4-C	35	38.5	27000	φ36 × 16 mm	C	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-27000-K-CE4-BL	35	38.5	27000	φ36 × 16 mm	BL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-27000-K-CE4-CL	35	38.5	27000	φ36 × 16 mm	CL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE5-A	35	38.5	36000	φ36 × 18 mm	A	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE5-B	35	38.5	36000	φ36 × 18 mm	B	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE5-C	35	38.5	36000	φ36 × 18 mm	C	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE5-BL	35	38.5	36000	φ36 × 18 mm	BL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE5-CL	35	38.5	36000	φ36 × 18 mm	CL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE6-A	35	38.5	36000	φ36 × 20 mm	A	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE6-B	35	38.5	36000	φ36 × 20 mm	B	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE6-C	35	38.5	36000	φ36 × 20 mm	C	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE6-BL	35	38.5	36000	φ36 × 20 mm	BL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-36000-K-CE6-CL	35	38.5	36000	φ36 × 20 mm	CL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-45000-K-CE7-A	35	38.5	45000	φ36 × 24 mm	A	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-45000-K-CE7-B	35	38.5	45000	φ36 × 24 mm	B	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-45000-K-CE7-C	35	38.5	45000	φ36 × 24 mm	C	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-45000-K-CE7-BL	35	38.5	45000	φ36 × 24 mm	BL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-35-45000-K-CE7-CL	35	38.5	45000	φ36 × 24 mm	CL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-550-K-CA1-A	50	55	550	φ12 × 8 mm	A	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-50-550-K-CA1-B	50	55	550	φ12 × 8 mm	B	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-50-550-K-CA1-C	50	55	550	φ12 × 8 mm	C	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-50-700-K-CA2-A	50	55	700	φ12 × 10 mm	A	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-50-700-K-CA2-B	50	55	700	φ12 × 10 mm	B	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-50-700-K-CA2-C	50	55	700	φ12 × 10 mm	C	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-50-1100-K-CA3-A	50	55	1100	φ12 × 12 mm	A	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-50-1100-K-CA3-B	50	55	1100	φ12 × 12 mm	B	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-50-1100-K-CA3-C	50	55	1100	φ12 × 12 mm	C	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-50-1100-K-CB1-A	50	55	1100	φ16 × 8 mm	A	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-1100-K-CB1-B	50	55	1100	φ16 × 8 mm	B	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-1100-K-CB1-C	50	55	1100	φ16 × 8 mm	C	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-1500-K-CB2-A	50	55	1500	φ16 × 10 mm	A	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-1500-K-CB2-B	50	55	1500	φ16 × 10 mm	B	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-1500-K-CB2-C	50	55	1500	φ16 × 10 mm	C	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-2200-K-CB3-A	50	55	2200	φ16 × 12 mm	A	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-2200-K-CB3-B	50	55	2200	φ16 × 12 mm	B	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-2200-K-CB3-C	50	55	2200	φ16 × 12 mm	C	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-3300-K-CB4-A	50	55	3300	φ16 × 16 mm	A	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-3300-K-CB4-B	50	55	3300	φ16 × 16 mm	B	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-3300-K-CB4-C	50	55	3300	φ16 × 16 mm	C	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-50-2500-K-CD1-A	50	55	2500	φ22 × 8 mm	A	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-2500-K-CD1-B	50	55	2500	φ22 × 8 mm	B	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-2500-K-CD1-C	50	55	2500	φ22 × 8 mm	C	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-2500-K-CD1-BL	50	55	2500	φ22 × 8 mm	BL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-2500-K-CD1-CL	50	55	2500	φ22 × 8 mm	CL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-3000-K-CD2-A	50	55	3000	φ22 × 10 mm	A	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-3000-K-CD2-B	50	55	3000	φ22 × 10 mm	B	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-3000-K-CD2-C	50	55	3000	φ22 × 10 mm	C	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-3000-K-CD2-BL	50	55	3000	φ22 × 10 mm	BL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-3000-K-CD2-CL	50	55	3000	φ22 × 10 mm	CL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-5000-K-CD3-A	50	55	5000	φ22 × 12 mm	A	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-5000-K-CD3-B	50	55	5000	φ22 × 12 mm	B	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-5000-K-CD3-C	50	55	5000	φ22 × 12 mm	C	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-5000-K-CD3-BL	50	55	5000	φ22 × 12 mm	BL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-5000-K-CD3-CL	50	55	5000	φ22 × 12 mm	CL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-7500-K-CD4-A	50	55	7500	φ22 × 16 mm	A	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-7500-K-CD4-B	50	55	7500	φ22 × 16 mm	B	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-7500-K-CD4-C	50	55	7500	φ22 × 16 mm	C	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-7500-K-CD4-BL	50	55	7500	φ22 × 16 mm	BL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-7500-K-CD4-CL	50	55	7500	φ22 × 16 mm	CL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-9000-K-CD5-A	50	55	9000	φ22 × 18 mm	A	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-9000-K-CD5-B	50	55	9000	φ22 × 18 mm	B	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-9000-K-CD5-C	50	55	9000	φ22 × 18 mm	C	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-9000-K-CD5-BL	50	55	9000	φ22 × 18 mm	BL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-9000-K-CD5-CL	50	55	9000	φ22 × 18 mm	CL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-10000-K-CD6-A	50	55	10000	φ22 × 20 mm	A	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-10000-K-CD6-B	50	55	10000	φ22 × 20 mm	B	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-10000-K-CD6-C	50	55	10000	φ22 × 20 mm	C	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-10000-K-CD6-BL	50	55	10000	φ22 × 20 mm	BL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-10000-K-CD6-CL	50	55	10000	φ22 × 20 mm	CL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-50-6000-K-CE1-A	50	55	6000	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-6000-K-CE1-B	50	55	6000	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-6000-K-CE1-C	50	55	6000	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-6000-K-CE1-BL	50	55	6000	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-6000-K-CE1-CL	50	55	6000	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-8000-K-CE2-A	50	55	8000	φ36 × 10 mm	A	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-8000-K-CE2-B	50	55	8000	φ36 × 10 mm	B	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-8000-K-CE2-C	50	55	8000	φ36 × 10 mm	C	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-8000-K-CE2-BL	50	55	8000	φ36 × 10 mm	BL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-8000-K-CE2-CL	50	55	8000	φ36 × 10 mm	CL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-12000-K-CE3-A	50	55	12000	φ36 × 12 mm	A	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-12000-K-CE3-B	50	55	12000	φ36 × 12 mm	B	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-12000-K-CE3-C	50	55	12000	φ36 × 12 mm	C	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-12000-K-CE3-BL	50	55	12000	φ36 × 12 mm	BL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-12000-K-CE3-CL	50	55	12000	φ36 × 12 mm	CL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-18000-K-CE4-A	50	55	18000	φ36 × 16 mm	A	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-18000-K-CE4-B	50	55	18000	φ36 × 16 mm	B	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-18000-K-CE4-C	50	55	18000	φ36 × 16 mm	C	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-18000-K-CE4-BL	50	55	18000	φ36 × 16 mm	BL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-18000-K-CE4-CL	50	55	18000	φ36 × 16 mm	CL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE5-A	50	55	24000	φ36 × 18 mm	A	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE5-B	50	55	24000	φ36 × 18 mm	B	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE5-C	50	55	24000	φ36 × 18 mm	C	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE5-BL	50	55	24000	φ36 × 18 mm	BL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE5-CL	50	55	24000	φ36 × 18 mm	CL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE6-A	50	55	24000	φ36 × 20 mm	A	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE6-B	50	55	24000	φ36 × 20 mm	B	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE6-C	50	55	24000	φ36 × 20 mm	C	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE6-BL	50	55	24000	φ36 × 20 mm	BL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-24000-K-CE6-CL	50	55	24000	φ36 × 20 mm	CL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-30000-K-CE7-A	50	55	30000	φ36 × 24 mm	A	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-30000-K-CE7-B	50	55	30000	φ36 × 24 mm	B	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-30000-K-CE7-C	50	55	30000	φ36 × 24 mm	C	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-30000-K-CE7-BL	50	55	30000	φ36 × 24 mm	BL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-50-30000-K-CE7-CL	50	55	30000	φ36 × 24 mm	CL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-400-K-CA1-A	63	69.3	400	φ12 × 8 mm	A	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-63-400-K-CA1-B	63	69.3	400	φ12 × 8 mm	B	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-63-400-K-CA1-C	63	69.3	400	φ12 × 8 mm	C	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-63-500-K-CA2-A	63	69.3	500	φ12 × 10 mm	A	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-63-500-K-CA2-B	63	69.3	500	φ12 × 10 mm	B	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-63-500-K-CA2-C	63	69.3	500	φ12 × 10 mm	C	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-63-800-K-CA3-A	63	69.3	800	φ12 × 12 mm	A	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-63-800-K-CA3-B	63	69.3	800	φ12 × 12 mm	B	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-63-800-K-CA3-C	63	69.3	800	φ12 × 12 mm	C	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-63-500-K-CB1-A	63	69.3	500	φ16 × 8 mm	A	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-500-K-CB1-B	63	69.3	500	φ16 × 8 mm	B	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-500-K-CB1-C	63	69.3	500	φ16 × 8 mm	C	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-600-K-CB2-A	63	69.3	600	φ16 × 10 mm	A	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-600-K-CB2-B	63	69.3	600	φ16 × 10 mm	B	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-600-K-CB2-C	63	69.3	600	φ16 × 10 mm	C	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-1000-K-CB3-A	63	69.3	1000	φ16 × 12 mm	A	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-1000-K-CB3-B	63	69.3	1000	φ16 × 12 mm	B	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-1000-K-CB3-C	63	69.3	1000	φ16 × 12 mm	C	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-1500-K-CB4-A	63	69.3	1500	φ16 × 16 mm	A	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-1500-K-CB4-B	63	69.3	1500	φ16 × 16 mm	B	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-1500-K-CB4-C	63	69.3	1500	φ16 × 16 mm	C	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-63-1000-K-CD1-A	63	69.3	1000	φ22 × 8 mm	A	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-1000-K-CD1-B	63	69.3	1000	φ22 × 8 mm	B	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-1000-K-CD1-C	63	69.3	1000	φ22 × 8 mm	C	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-1000-K-CD1-BL	63	69.3	1000	φ22 × 8 mm	BL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-1000-K-CD1-CL	63	69.3	1000	φ22 × 8 mm	CL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-1300-K-CD2-A	63	69.3	1300	φ22 × 10 mm	A	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-1300-K-CD2-B	63	69.3	1300	φ22 × 10 mm	B	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-1300-K-CD2-C	63	69.3	1300	φ22 × 10 mm	C	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-1300-K-CD2-BL	63	69.3	1300	φ22 × 10 mm	BL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-1300-K-CD2-CL	63	69.3	1300	φ22 × 10 mm	CL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-2000-K-CD3-A	63	69.3	2000	φ22 × 12 mm	A	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-2000-K-CD3-B	63	69.3	2000	φ22 × 12 mm	B	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-2000-K-CD3-C	63	69.3	2000	φ22 × 12 mm	C	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-2000-K-CD3-BL	63	69.3	2000	φ22 × 12 mm	BL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-2000-K-CD3-CL	63	69.3	2000	φ22 × 12 mm	CL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3000-K-CD4-A	63	69.3	3000	φ22 × 16 mm	A	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3000-K-CD4-B	63	69.3	3000	φ22 × 16 mm	B	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3000-K-CD4-C	63	69.3	3000	φ22 × 16 mm	C	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3000-K-CD4-BL	63	69.3	3000	φ22 × 16 mm	BL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3000-K-CD4-CL	63	69.3	3000	φ22 × 16 mm	CL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3900-K-CD5-A	63	69.3	3900	φ22 × 18 mm	A	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3900-K-CD5-B	63	69.3	3900	φ22 × 18 mm	B	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3900-K-CD5-C	63	69.3	3900	φ22 × 18 mm	C	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3900-K-CD5-BL	63	69.3	3900	φ22 × 18 mm	BL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3900-K-CD5-CL	63	69.3	3900	φ22 × 18 mm	CL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-4000-K-CD6-A	63	69.3	4000	φ22 × 20 mm	A	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-4000-K-CD6-B	63	69.3	4000	φ22 × 20 mm	B	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-4000-K-CD6-C	63	69.3	4000	φ22 × 20 mm	C	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-4000-K-CD6-BL	63	69.3	4000	φ22 × 20 mm	BL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-4000-K-CD6-CL	63	69.3	4000	φ22 × 20 mm	CL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-63-3000-K-CE1-A	63	69.3	3000	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-3000-K-CE1-B	63	69.3	3000	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-3000-K-CE1-C	63	69.3	3000	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-3000-K-CE1-BL	63	69.3	3000	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-3000-K-CE1-CL	63	69.3	3000	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-4000-K-CE2-A	63	69.3	4000	φ36 × 10 mm	A	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-4000-K-CE2-B	63	69.3	4000	φ36 × 10 mm	B	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-4000-K-CE2-C	63	69.3	4000	φ36 × 10 mm	C	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-4000-K-CE2-BL	63	69.3	4000	φ36 × 10 mm	BL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-4000-K-CE2-CL	63	69.3	4000	φ36 × 10 mm	CL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-6000-K-CE3-A	63	69.3	6000	φ36 × 12 mm	A	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-6000-K-CE3-B	63	69.3	6000	φ36 × 12 mm	B	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-6000-K-CE3-C	63	69.3	6000	φ36 × 12 mm	C	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-6000-K-CE3-BL	63	69.3	6000	φ36 × 12 mm	BL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-6000-K-CE3-CL	63	69.3	6000	φ36 × 12 mm	CL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-9000-K-CE4-A	63	69.3	9000	φ36 × 16 mm	A	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-9000-K-CE4-B	63	69.3	9000	φ36 × 16 mm	B	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-9000-K-CE4-C	63	69.3	9000	φ36 × 16 mm	C	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-9000-K-CE4-BL	63	69.3	9000	φ36 × 16 mm	BL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-9000-K-CE4-CL	63	69.3	9000	φ36 × 16 mm	CL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE5-A	63	69.3	12000	φ36 × 18 mm	A	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE5-B	63	69.3	12000	φ36 × 18 mm	B	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE5-C	63	69.3	12000	φ36 × 18 mm	C	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE5-BL	63	69.3	12000	φ36 × 18 mm	BL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE5-CL	63	69.3	12000	φ36 × 18 mm	CL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE6-A	63	69.3	12000	φ36 × 20 mm	A	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE6-B	63	69.3	12000	φ36 × 20 mm	B	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE6-C	63	69.3	12000	φ36 × 20 mm	C	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE6-BL	63	69.3	12000	φ36 × 20 mm	BL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-12000-K-CE6-CL	63	69.3	12000	φ36 × 20 mm	CL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-15000-K-CE7-A	63	69.3	15000	φ36 × 24 mm	A	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-15000-K-CE7-B	63	69.3	15000	φ36 × 24 mm	B	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-15000-K-CE7-C	63	69.3	15000	φ36 × 24 mm	C	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-15000-K-CE7-BL	63	69.3	15000	φ36 × 24 mm	BL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-63-15000-K-CE7-CL	63	69.3	15000	φ36 × 24 mm	CL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-300-K-CA1-A	80	88	300	φ12 × 8 mm	A	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-80-300-K-CA1-B	80	88	300	φ12 × 8 mm	B	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-80-300-K-CA1-C	80	88	300	φ12 × 8 mm	C	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-80-360-K-CA2-A	80	88	360	φ12 × 10 mm	A	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-80-360-K-CA2-B	80	88	360	φ12 × 10 mm	B	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-80-360-K-CA2-C	80	88	360	φ12 × 10 mm	C	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-80-600-K-CA3-A	80	88	600	φ12 × 12 mm	A	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-80-600-K-CA3-B	80	88	600	φ12 × 12 mm	B	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-80-600-K-CA3-C	80	88	600	φ12 × 12 mm	C	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-80-400-K-CB1-A	80	88	400	φ16 × 8 mm	A	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-400-K-CB1-B	80	88	400	φ16 × 8 mm	B	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-400-K-CB1-C	80	88	400	φ16 × 8 mm	C	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-500-K-CB2-A	80	88	500	φ16 × 10 mm	A	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-500-K-CB2-B	80	88	500	φ16 × 10 mm	B	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-500-K-CB2-C	80	88	500	φ16 × 10 mm	C	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-800-K-CB3-A	80	88	800	φ16 × 12 mm	A	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-800-K-CB3-B	80	88	800	φ16 × 12 mm	B	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-800-K-CB3-C	80	88	800	φ16 × 12 mm	C	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-1200-K-CB4-A	80	88	1200	φ16 × 16 mm	A	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-1200-K-CB4-B	80	88	1200	φ16 × 16 mm	B	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-1200-K-CB4-C	80	88	1200	φ16 × 16 mm	C	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-80-800-K-CD1-A	80	88	800	φ22 × 8 mm	A	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-800-K-CD1-B	80	88	800	φ22 × 8 mm	B	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-800-K-CD1-C	80	88	800	φ22 × 8 mm	C	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-800-K-CD1-BL	80	88	800	φ22 × 8 mm	BL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-800-K-CD1-CL	80	88	800	φ22 × 8 mm	CL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1100-K-CD2-A	80	88	1100	φ22 × 10 mm	A	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1100-K-CD2-B	80	88	1100	φ22 × 10 mm	B	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1100-K-CD2-C	80	88	1100	φ22 × 10 mm	C	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1100-K-CD2-BL	80	88	1100	φ22 × 10 mm	BL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1100-K-CD2-CL	80	88	1100	φ22 × 10 mm	CL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1600-K-CD3-A	80	88	1600	φ22 × 12 mm	A	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1600-K-CD3-B	80	88	1600	φ22 × 12 mm	B	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1600-K-CD3-C	80	88	1600	φ22 × 12 mm	C	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1600-K-CD3-BL	80	88	1600	φ22 × 12 mm	BL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-1600-K-CD3-CL	80	88	1600	φ22 × 12 mm	CL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-2400-K-CD4-A	80	88	2400	φ22 × 16 mm	A	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-2400-K-CD4-B	80	88	2400	φ22 × 16 mm	B	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-2400-K-CD4-C	80	88	2400	φ22 × 16 mm	C	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-2400-K-CD4-BL	80	88	2400	φ22 × 16 mm	BL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-2400-K-CD4-CL	80	88	2400	φ22 × 16 mm	CL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD5-A	80	88	3300	φ22 × 18 mm	A	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD5-B	80	88	3300	φ22 × 18 mm	B	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD5-C	80	88	3300	φ22 × 18 mm	C	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD5-BL	80	88	3300	φ22 × 18 mm	BL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD5-CL	80	88	3300	φ22 × 18 mm	CL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD6-A	80	88	3300	φ22 × 20 mm	A	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD6-B	80	88	3300	φ22 × 20 mm	B	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD6-C	80	88	3300	φ22 × 20 mm	C	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD6-BL	80	88	3300	φ22 × 20 mm	BL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-3300-K-CD6-CL	80	88	3300	φ22 × 20 mm	CL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-80-2000-K-CE1-A	80	88	2000	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-2000-K-CE1-B	80	88	2000	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-2000-K-CE1-C	80	88	2000	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-2000-K-CE1-BL	80	88	2000	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-2000-K-CE1-CL	80	88	2000	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-3000-K-CE2-A	80	88	3000	φ36 × 10 mm	A	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-3000-K-CE2-B	80	88	3000	φ36 × 10 mm	B	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-3000-K-CE2-C	80	88	3000	φ36 × 10 mm	C	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-3000-K-CE2-BL	80	88	3000	φ36 × 10 mm	BL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-3000-K-CE2-CL	80	88	3000	φ36 × 10 mm	CL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-4000-K-CE3-A	80	88	4000	φ36 × 12 mm	A	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-4000-K-CE3-B	80	88	4000	φ36 × 12 mm	B	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-4000-K-CE3-C	80	88	4000	φ36 × 12 mm	C	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-4000-K-CE3-BL	80	88	4000	φ36 × 12 mm	BL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-4000-K-CE3-CL	80	88	4000	φ36 × 12 mm	CL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-6000-K-CE4-A	80	88	6000	φ36 × 16 mm	A	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-6000-K-CE4-B	80	88	6000	φ36 × 16 mm	B	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-6000-K-CE4-C	80	88	6000	φ36 × 16 mm	C	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-6000-K-CE4-BL	80	88	6000	φ36 × 16 mm	BL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-6000-K-CE4-CL	80	88	6000	φ36 × 16 mm	CL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE5-A	80	88	8000	φ36 × 18 mm	A	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE5-B	80	88	8000	φ36 × 18 mm	B	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE5-C	80	88	8000	φ36 × 18 mm	C	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE5-BL	80	88	8000	φ36 × 18 mm	BL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE5-CL	80	88	8000	φ36 × 18 mm	CL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE6-A	80	88	8000	φ36 × 20 mm	A	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE6-B	80	88	8000	φ36 × 20 mm	B	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE6-C	80	88	8000	φ36 × 20 mm	C	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE6-BL	80	88	8000	φ36 × 20 mm	BL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-8000-K-CE6-CL	80	88	8000	φ36 × 20 mm	CL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-10000-K-CE7-A	80	88	10000	φ36 × 24 mm	A	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-10000-K-CE7-B	80	88	10000	φ36 × 24 mm	B	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-10000-K-CE7-C	80	88	10000	φ36 × 24 mm	C	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-10000-K-CE7-BL	80	88	10000	φ36 × 24 mm	BL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-80-10000-K-CE7-CL	80	88	10000	φ36 × 24 mm	CL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-250-K-CA1-A	100	110	250	φ12 × 8 mm	A	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-100-250-K-CA1-B	100	110	250	φ12 × 8 mm	B	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-100-250-K-CA1-C	100	110	250	φ12 × 8 mm	C	D: 12+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-100-300-K-CA2-A	100	110	300	φ12 × 10 mm	A	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-100-300-K-CA2-B	100	110	300	φ12 × 10 mm	B	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-100-300-K-CA2-C	100	110	300	φ12 × 10 mm	C	D: 12+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-100-500-K-CA3-A	100	110	500	φ12 × 12 mm	A	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-100-500-K-CA3-B	100	110	500	φ12 × 12 mm	B	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-100-500-K-CA3-C	100	110	500	φ12 × 12 mm	C	D: 12+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 4+/-0.38 mm
CAK36C-100-150-K-CB1-A	100	110	150	φ16 × 8 mm	A	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-150-K-CB1-B	100	110	150	φ16 × 8 mm	B	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-150-K-CB1-C	100	110	150	φ16 × 8 mm	C	D: 16+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-180-K-CB2-A	100	110	180	φ16 × 10 mm	A	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-180-K-CB2-B	100	110	180	φ16 × 10 mm	B	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-180-K-CB2-C	100	110	180	φ16 × 10 mm	C	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-300-K-CB3-A	100	110	300	φ16 × 12 mm	A	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-300-K-CB3-B	100	110	300	φ16 × 12 mm	B	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-300-K-CB3-C	100	110	300	φ16 × 12 mm	C	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-450-K-CB4-A	100	110	450	φ16 × 16 mm	A	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-450-K-CB4-B	100	110	450	φ16 × 16 mm	B	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-450-K-CB4-C	100	110	450	φ16 × 16 mm	C	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-100-300-K-CD1-A	100	110	300	φ22 × 8 mm	A	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-300-K-CD1-B	100	110	300	φ22 × 8 mm	B	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-300-K-CD1-C	100	110	300	φ22 × 8 mm	C	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-300-K-CD1-BL	100	110	300	φ22 × 8 mm	BL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-300-K-CD1-CL	100	110	300	φ22 × 8 mm	CL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-400-K-CD2-A	100	110	400	φ22 × 10 mm	A	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-400-K-CD2-B	100	110	400	φ22 × 10 mm	B	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-400-K-CD2-C	100	110	400	φ22 × 10 mm	C	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-400-K-CD2-BL	100	110	400	φ22 × 10 mm	BL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-400-K-CD2-CL	100	110	400	φ22 × 10 mm	CL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-600-K-CD3-A	100	110	600	φ22 × 12 mm	A	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-600-K-CD3-B	100	110	600	φ22 × 12 mm	B	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-600-K-CD3-C	100	110	600	φ22 × 12 mm	C	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-600-K-CD3-BL	100	110	600	φ22 × 12 mm	BL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-600-K-CD3-CL	100	110	600	φ22 × 12 mm	CL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-900-K-CD4-A	100	110	900	φ22 × 16 mm	A	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-900-K-CD4-B	100	110	900	φ22 × 16 mm	B	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-900-K-CD4-C	100	110	900	φ22 × 16 mm	C	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-900-K-CD4-BL	100	110	900	φ22 × 16 mm	BL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-900-K-CD4-CL	100	110	900	φ22 × 16 mm	CL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD5-A	100	110	1200	φ22 × 18 mm	A	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD5-B	100	110	1200	φ22 × 18 mm	B	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD5-C	100	110	1200	φ22 × 18 mm	C	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD5-BL	100	110	1200	φ22 × 18 mm	BL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD5-CL	100	110	1200	φ22 × 18 mm	CL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD6-A	100	110	1200	φ22 × 20 mm	A	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD6-B	100	110	1200	φ22 × 20 mm	B	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD6-C	100	110	1200	φ22 × 20 mm	C	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD6-BL	100	110	1200	φ22 × 20 mm	BL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-1200-K-CD6-CL	100	110	1200	φ22 × 20 mm	CL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-100-900-K-CE1-A	100	110	900	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-900-K-CE1-B	100	110	900	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-900-K-CE1-C	100	110	900	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-900-K-CE1-BL	100	110	900	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-900-K-CE1-CL	100	110	900	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1200-K-CE2-A	100	110	1200	φ36 × 10 mm	A	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1200-K-CE2-B	100	110	1200	φ36 × 10 mm	B	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1200-K-CE2-C	100	110	1200	φ36 × 10 mm	C	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1200-K-CE2-BL	100	110	1200	φ36 × 10 mm	BL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1200-K-CE2-CL	100	110	1200	φ36 × 10 mm	CL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1800-K-CE3-A	100	110	1800	φ36 × 12 mm	A	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1800-K-CE3-B	100	110	1800	φ36 × 12 mm	B	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1800-K-CE3-C	100	110	1800	φ36 × 12 mm	C	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1800-K-CE3-BL	100	110	1800	φ36 × 12 mm	BL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-1800-K-CE3-CL	100	110	1800	φ36 × 12 mm	CL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-2700-K-CE4-A	100	110	2700	φ36 × 16 mm	A	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-2700-K-CE4-B	100	110	2700	φ36 × 16 mm	B	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-2700-K-CE4-C	100	110	2700	φ36 × 16 mm	C	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-2700-K-CE4-BL	100	110	2700	φ36 × 16 mm	BL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-2700-K-CE4-CL	100	110	2700	φ36 × 16 mm	CL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE5-A	100	110	3600	φ36 × 18 mm	A	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE5-B	100	110	3600	φ36 × 18 mm	B	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE5-C	100	110	3600	φ36 × 18 mm	C	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE5-BL	100	110	3600	φ36 × 18 mm	BL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE5-CL	100	110	3600	φ36 × 18 mm	CL	D: 36+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE6-A	100	110	3600	φ36 × 20 mm	A	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE6-B	100	110	3600	φ36 × 20 mm	B	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE6-C	100	110	3600	φ36 × 20 mm	C	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE6-BL	100	110	3600	φ36 × 20 mm	BL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-3600-K-CE6-CL	100	110	3600	φ36 × 20 mm	CL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-4500-K-CE7-A	100	110	4500	φ36 × 24 mm	A	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-4500-K-CE7-B	100	110	4500	φ36 × 24 mm	B	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-4500-K-CE7-C	100	110	4500	φ36 × 24 mm	C	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-4500-K-CE7-BL	100	110	4500	φ36 × 24 mm	BL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-100-4500-K-CE7-CL	100	110	4500	φ36 × 24 mm	CL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-100-K-CB2-A	125	137.5	100	φ16 × 10 mm	A	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-125-100-K-CB2-B	125	137.5	100	φ16 × 10 mm	B	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-125-100-K-CB2-C	125	137.5	100	φ16 × 10 mm	C	D: 16+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-125-160-K-CB3-A	125	137.5	160	φ16 × 12 mm	A	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-125-160-K-CB3-B	125	137.5	160	φ16 × 12 mm	B	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-125-160-K-CB3-C	125	137.5	160	φ16 × 12 mm	C	D: 16+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-125-240-K-CB4-A	125	137.5	240	φ16 × 16 mm	A	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-125-240-K-CB4-B	125	137.5	240	φ16 × 16 mm	B	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-125-240-K-CB4-C	125	137.5	240	φ16 × 16 mm	C	D: 16+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 5.08+/-0.38 mm
CAK36C-125-220-K-CD1-A	125	137.5	220	φ22 × 8 mm	A	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-220-K-CD1-B	125	137.5	220	φ22 × 8 mm	B	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-220-K-CD1-C	125	137.5	220	φ22 × 8 mm	C	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-220-K-CD1-BL	125	137.5	220	φ22 × 8 mm	BL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-220-K-CD1-CL	125	137.5	220	φ22 × 8 mm	CL	D: 22+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-300-K-CD2-A	125	137.5	300	φ22 × 10 mm	A	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-300-K-CD2-B	125	137.5	300	φ22 × 10 mm	B	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-300-K-CD2-C	125	137.5	300	φ22 × 10 mm	C	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-300-K-CD2-BL	125	137.5	300	φ22 × 10 mm	BL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-300-K-CD2-CL	125	137.5	300	φ22 × 10 mm	CL	D: 22+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-440-K-CD3-A	125	137.5	440	φ22 × 12 mm	A	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-440-K-CD3-B	125	137.5	440	φ22 × 12 mm	B	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-440-K-CD3-C	125	137.5	440	φ22 × 12 mm	C	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-440-K-CD3-BL	125	137.5	440	φ22 × 12 mm	BL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-440-K-CD3-CL	125	137.5	440	φ22 × 12 mm	CL	D: 22+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-660-K-CD4-A	125	137.5	660	φ22 × 16 mm	A	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-660-K-CD4-B	125	137.5	660	φ22 × 16 mm	B	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-660-K-CD4-C	125	137.5	660	φ22 × 16 mm	C	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-660-K-CD4-BL	125	137.5	660	φ22 × 16 mm	BL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-660-K-CD4-CL	125	137.5	660	φ22 × 16 mm	CL	D: 22+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-900-K-CD5-A	125	137.5	900	φ22 × 18 mm	A	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-900-K-CD5-B	125	137.5	900	φ22 × 18 mm	B	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-900-K-CD5-C	125	137.5	900	φ22 × 18 mm	C	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-900-K-CD5-BL	125	137.5	900	φ22 × 18 mm	BL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-900-K-CD5-CL	125	137.5	900	φ22 × 18 mm	CL	D: 22+/-0.5 mm; H: 18+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-880-K-CD6-A	125	137.5	880	φ22 × 20 mm	A	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-880-K-CD6-B	125	137.5	880	φ22 × 20 mm	B	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-880-K-CD6-C	125	137.5	880	φ22 × 20 mm	C	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-880-K-CD6-BL	125	137.5	880	φ22 × 20 mm	BL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-880-K-CD6-CL	125	137.5	880	φ22 × 20 mm	CL	D: 22+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 7.5+/-0.38 mm
CAK36C-125-800-K-CE1-A	125	137.5	800	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-800-K-CE1-B	125	137.5	800	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-800-K-CE1-C	125	137.5	800	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-800-K-CE1-BL	125	137.5	800	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-800-K-CE1-CL	125	137.5	800	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1100-K-CE2-A	125	137.5	1100	φ36 × 10 mm	A	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1100-K-CE2-B	125	137.5	1100	φ36 × 10 mm	B	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1100-K-CE2-C	125	137.5	1100	φ36 × 10 mm	C	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1100-K-CE2-BL	125	137.5	1100	φ36 × 10 mm	BL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1100-K-CE2-CL	125	137.5	1100	φ36 × 10 mm	CL	D: 36+/-0.5 mm; H: 10+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1600-K-CE3-A	125	137.5	1600	φ36 × 12 mm	A	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1600-K-CE3-B	125	137.5	1600	φ36 × 12 mm	B	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1600-K-CE3-C	125	137.5	1600	φ36 × 12 mm	C	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1600-K-CE3-BL	125	137.5	1600	φ36 × 12 mm	BL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-1600-K-CE3-CL	125	137.5	1600	φ36 × 12 mm	CL	D: 36+/-0.5 mm; H: 12+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-2400-K-CE4-A	125	137.5	2400	φ36 × 16 mm	A	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-2400-K-CE4-B	125	137.5	2400	φ36 × 16 mm	B	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-2400-K-CE4-C	125	137.5	2400	φ36 × 16 mm	C	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-2400-K-CE4-BL	125	137.5	2400	φ36 × 16 mm	BL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-2400-K-CE4-CL	125	137.5	2400	φ36 × 16 mm	CL	D: 36+/-0.5 mm; H: 16+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE5-A	125	137.5	3300	φ36 × 8 mm	A	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE5-B	125	137.5	3300	φ36 × 8 mm	B	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE5-C	125	137.5	3300	φ36 × 8 mm	C	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE5-BL	125	137.5	3300	φ36 × 8 mm	BL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE5-CL	125	137.5	3300	φ36 × 8 mm	CL	D: 36+/-0.5 mm; H: 8+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE6-A	125	137.5	3300	φ36 × 20 mm	A	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE6-B	125	137.5	3300	φ36 × 20 mm	B	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE6-C	125	137.5	3300	φ36 × 20 mm	C	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE6-BL	125	137.5	3300	φ36 × 20 mm	BL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-3300-K-CE6-CL	125	137.5	3300	φ36 × 20 mm	CL	D: 36+/-0.5 mm; H: 20+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-4000-K-CE7-A	125	137.5	4000	φ36 × 24 mm	A	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-4000-K-CE7-B	125	137.5	4000	φ36 × 24 mm	B	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-4000-K-CE7-C	125	137.5	4000	φ36 × 24 mm	C	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-4000-K-CE7-BL	125	137.5	4000	φ36 × 24 mm	BL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm
CAK36C-125-4000-K-CE7-CL	125	137.5	4000	φ36 × 24 mm	CL	D: 36+/-0.5 mm; H: 24+/-0.5 mm L1: 7+/-0.5 mm; L2: 5.84+/-0.76 mm D1: 10.16+/-0.38 mm

Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 18000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 18000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
Read more

Add to Wishlist

Quick View

Add to Wishlist

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor
10 V / 18000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

CAK36C Hermetically Sealed High-Temperature (150degC) High-Energy Hybrid Tantalum Capacitor

10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 12000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 16000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 18000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 18000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor

10 V / 18000 uF CAK36C Hermetically Sealed High-Energy Composite Tantalum Capacitor
